Siemens siprotec 7SA522 User Manual

Functions
6-146 7SA522 Manual
C53000-G1176-C119-2
6.9.3 Settings
Addr. Setting Title Setting Options Default Setting Comments
2601 Operating Mode ON
Only Active with Loss of VT
sec. circuit
OFF
Only Active with
Loss of VT sec. cir-
cuit
Operating mode
2680 SOTF Time DELAY 0.00..30.00 sec 0.00 sec Trip time delay after SOTF
2610 Iph>> 0.10..25.00 A 2.00 A Iph>> Pickup
2611 T Iph>> 0.00..30.00 sec 0.30 sec T Iph>> Time delay
2612 3I0>> PICKUP 0.05..25.00 A 0.50 A 3I0>> Pickup
2613 T 3I0>> 0.00..30.00 sec 0.30 sec T 3I0>> Time delay
2614 I>> Telep/BI NO
YES
YES Instantaneous trip via Teleprot./
BI
2615 I>> SOTF NO
YES
NO Instantaneous trip after Swit-
chOnToFault
2620 Iph> 0.10..25.00 A 1.50 A Iph> Pickup
2621 T Iph> 0.00..30.00 sec 0.50 sec T Iph> Time delay
2622 3I0> 0.05..25.00 A 0.20 A 3I0> Pickup
2623 T 3I0> 0.00..30.00 sec 0.50 sec T 3I0> Time delay
2624 I> Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
2625 I> SOTF NO
YES
NO Instantaneous trip after Swit-
chOnToFault
2640 Ip> 0.10..4.00 A ∞ A Ip> Pickup
2641 Ip MinT-DELAY 0.00..30.00 sec 1.20 sec Ip Minimum Time Delay
2642 T Ip Time Dial 0.05..3.00 sec 0.50 sec T Ip Time Dial
2643 Time Dial TD Ip 0.50..15.00 5.00 Time Dial TD Ip
2644 T Ip Time Dial 0.05..15.00 sec 1.35 sec T Ip Time Dial
2645 T Ip Max 0.00..30.00 sec 5.80 sec T Ip Maximum Time Delay
2646 T Ip Add 0.00..30.00 sec 0.00 sec T Ip Additional Time Delay
2650 3I0p PICKUP 0.05..4.00 A ∞ A 3I0p Pickup
2651 3I0p MinTdelay 0.00..30.00 sec 1.20 sec 3I0p Minimum Time Delay
2652 T 3I0p TimeDial 0.05..3.00 sec 0.50 sec T 3I0p Time Dial
2653 TimeDial TD3I0p 0.50..15.00 5.00 Time Dial TD 3I0p
2654 T 3I0p TimeDial 0.05..15.00 sec 1.35 sec T 3I0p Time Dial
2655 T 3I0Pmax 0.00..30.00 sec 5.80 sec T 3I0Pmax Maximum Time
Delay
2656 T 3I0p Add 0.00..30.00 sec 0.00 sec T 3I0p Additional Time Delay
