Siemens siprotec 7SA522 User Manual

Functions
6-297SA522 Manual
C53000-G1176-C119-2
382 >Only 1ph AR >External AR programmed for 1phase only
383 >Enable ARzones >Enable all AR Zones / Stages
385 >Lockout SET >Lockout SET
386 >Lockout RESET >Lockout RESET
530 LOCKOUT LOCKOUT is active
501 Relay PICKUP Relay PICKUP
503 Relay PICKUP L1 Relay PICKUP Phase L1
504 Relay PICKUP L2 Relay PICKUP Phase L2
505 Relay PICKUP L3 Relay PICKUP Phase L3
506 Relay PICKUP E Relay PICKUP Earth
507 Relay TRIP L1 Relay TRIP command Phase L1
508 Relay TRIP L2 Relay TRIP command Phase L2
509 Relay TRIP L3 Relay TRIP command Phase L3
511 Relay TRIP Relay GENERAL TRIP command
512 Relay TRIP 1pL1 Relay TRIP command - Only Phase L1
513 Relay TRIP 1pL2 Relay TRIP command - Only Phase L2
514 Relay TRIP 1pL3 Relay TRIP command - Only Phase L3
515 Relay TRIP 3ph. Relay TRIP command Phases L123
536 Definitive TRIP Relay Definitive TRIP
510 Relay CLOSE Relay GENERAL CLOSE command
563 CB Alarm Supp CB alarm suppressed
533 IL1 = Primary fault current IL1
534 IL2 = Primary fault current IL2
535 IL3 = Primary fault current IL3
545 PU Time Time from Pickup to drop out
546 TRIP Time Time from Pickup to TRIP
560 Trip Coupled 3p Single-phase trip was coupled 3phase
561 Man.Clos.Detect Manual close signal detected
562 Man.Close Cmd CB CLOSE command for manual closing
F.No. Alarm Comments
