Functions
6-44 7SA522 Manual
C53000-G1176-C119-2
3781 Dis.TimeOut Tfw DistanceTime Out Forward PICKUP
3782 Dis.TimeOut Trv DistanceTime Out Reverse/Non-dir. PICKUP
3801 Dis.Gen. Trip Distance protection: General trip
3802 Dis.Trip 1pL1 Distance TRIP command - Only Phase L1
3803 Dis.Trip 1pL2 Distance TRIP command - Only Phase L2
3804 Dis.Trip 1pL3 Distance TRIP command - Only Phase L3
3805 Dis.Trip 3p Distance TRIP command Phases L123
3811 Dis.TripZ1/1p Distance TRIP single-phase Z1
3823 DisTRIP3p. Z1sf DisTRIP 3phase in Z1 with single-ph Flt.
3824 DisTRIP3p. Z1mf DisTRIP 3phase in Z1 with multi-ph Flt.
3813 Dis.TripZ1B1p Distance TRIP single-phase Z1B
3825 DisTRIP3p.Z1Bsf DisTRIP 3phase in Z1B with single-ph Flt
3826 DisTRIP3p Z1Bmf DisTRIP 3phase in Z1B with multi-ph Flt.
3816 Dis.TripZ2/1p Distance TRIP single-phase Z2
3817 Dis.TripZ2/3p Distance TRIP 3phase in Z2
3818 Dis.TripZ3/T3 Distance TRIP 3phase in Z3
3821 Dis.TRIP 3p. Z4 Distance TRIP 3phase in Z4
3822 Dis.TRIP 3p. Z5 Distance TRIP 3phase in Z5
3850 DisTRIP Z1B Tel DisTRIP Z1B with Teleprotection scheme
3695 Dis Pickup ϕ L1 Dist.: Phi phase L1 Pickup
3696 Dis Pickup ϕ L2 Dist.: Phi phase L2 Pickup
3697 Dis Pickup ϕ L3 Dist.: Phi phase L3 Pickup
