In the other operating modes, manual adjustments are only accepted if the synchroni-
zation is momentarily lost. The messages “time error ON” and “time error OFF” are giv-
en when manually changing the year in the IRIG B mode.
Without healthy or external time synchronisation the free running date and time can
also be relatively
adjusted (+/– 23:59:59) using the entry field 'LII²WLPH.
This input possibility is not to be confused with the parameter 2IIVHW (see Section
5.7), which affects the specific general offset to the received synchronization time of
the radio clock receiver (e.g. local time vs. GMT time).
From the
Device Front
With a device ready for operation, first press the key. The 0$,10(18 appears.
Select 6HWWLQJV, and in the sub-menu 6(783(;75$6. To set the date and time
manually, choose the selection 'DWH7LPH and move to the '$7(7,0( display us-
ing the key. See Figure 7-25.
Figure 7-25 Manual date and time adjustment from the front panel
To change one of the previous settings (date, time, differential time), mark the item us-
ing the and keys, and then press the key.
The actual setting appears in a frame with a blinking cursor. Overwrite this setting with
the desired new one using the number keys. Be careful to enter the format properly.
Confirm the change with the key.
To change the time offset or the tolerance time for a clock error signal, select &ORFN
6HWXS under 6(783(;75$6, as shown in Figure 7-26. Under 2IIVHW, the time off-
set can be changed. Under (UURU7LPH, the time delay for the alarm can be adjust-
ed. These adjustments are done in the same manner as setting the time, by overwrit-
ing the displayed values and confirming with the key.
To return to the S(783(;75$6 level, press the key, several times if necessary. To
return to the 0$,10(18, press the key.
Figure 7-26 Date and time settings from the front panel
MENU
6(783(;75$6

!'DWH7LPH²!
!&ORFN6HWXS²!
'$7(7,0(
6WDWXV
!
'LII²WLPH
ENTER
ENTER
ENTER
MENU
6(783(;75$6

!'DWH7LPH²!
!&ORFN6HWXS²!
&/2&.6(783

2IIVHW!PLQ
(UURU7LPHPLQ
6RXUFH,QWHUQDO
