A-17SA522 Manual
C53000-G1176-C119-2
Appendix A
This appendix is primarily a reference for the experienced user. This Chapter provides
ordering information for the models of 7SA522. General diagrams indicating the termi-
nal connections of the 7SA522 models are included. Connection examples show the
proper connections of the device to primary equipment in typical power system con-
figurations.
1.1 Ordering Information and Accessories A-2
1.2 General Diagrams A-6
1.3 Connection Examples A-14
1.4 Preset Configurations A-21
1.5 Protocol Dependent Functions A-24
