Appendix
B-2
2.1 Settings
Addr. Setting Title Function Setting Options Default Setting Comments
103 Grp Chge OPTION Scope of Functions Disabled
Enabled
Disabled Setting Group Change Option
110 Trip mode Scope of Functions 3pole only
1-/3pole
3pole only Trip mode
112 Phase Distance Scope of Functions Quadrilateral
MHO
Disabled
Quadrilateral Phase Distance
113 Earth Distance Scope of Functions Quadrilateral
MHO
Disabled
Quadrilateral Earth Distance
120 Power Swing Scope of Functions Disabled
Enabled
Disabled Power Swing detection
121 Teleprot. Dist. Scope of Functions PUTT
POTT
UNBLOCKING
BLOCKING
Disabled
Disabled Teleprotection for Distance prot.
122 DTT Direct Trip Scope of Functions Disabled
Enabled
Disabled DTT Direct Transfer Trip
124 SOTF Overcurr. Scope of Functions Disabled
Enabled
Disabled Instantaneous HighSpeed SOTF Over-
current
125 Weak Infeed Scope of Functions Disabled
Enabled
Disabled Weak Infeed (Trip and/or Echo)
126 Back-Up O/C Scope of Functions Disabled
TOC IEC
TOC ANSI
TOC IEC Backup overcurrent
131 Earth Fault O/C Scope of Functions Disabled
TOC IEC
TOC ANSI
TOC Logarithm.
Definite Time
Disabled Earth fault overcurrent
132 Teleprot. E/F Scope of Functions Dir.Comp.Pickup
UNBLOCKING
BLOCKING
Disabled
Disabled Teleprotection for Earth fault overcurr.
133 Auto Reclose Scope of Functions Disabled
1 AR-cycle
2 AR-cycles
3 AR-cycles
4 AR-cycles
5 AR-cycles
6 AR-cycles
7 AR-cycles
8 AR-cycles
ADT
Disabled Auto-Reclose Function
134 AR control mode Scope of Functions Pickup w/ Tact
Pickup w/o Tact
Trip w/ Tact
Trip w/o Tact
Pickup w/ Tact Auto-Reclose control mode
135 Synchro-Check Scope of Functions Disabled
Enabled
Disabled Synchronism and Voltage Check
137 Overvoltage Scope of Functions Disabled
Enabled
Disabled Overvoltage
138 Fault Locator Scope of Functions Disabled
Enabled
Enabled Fault Locator
139 BREAKER FAIL-
URE
Scope of Functions Disabled
Enabled
Disabled Breaker Failure Protection
