Appendix
B-4
302 CHANGE Change Group Group A
Group B
Group C
Group D
Binary Input
Protocol
Group A Change to Another Setting Group
402A WAVEFORM CAP-
TURE
Oscillographic Fault
Records
Save with Pickup
Save with TRIP
Start with TRIP
Save with Pickup Waveform Capture
403A SCOPE OF WAVE-
FORM DATA
Oscillographic Fault
Records
Fault event
Power System fault
Fault event Scope of Waveform Data
410 MAX. LENGTH Oscillographic Fault
Records
0.30..5.00 sec 1.00 sec Max. length of a Waveform Capture
Record
411 PRE. TRIG. TIME Oscillographic Fault
Records
0.05..0.50 sec 0.10 sec Captured Waveform Prior to Trigger
412 POST REC. TIME Oscillographic Fault
Records
0.05..0.50 sec 0.10 sec Captured Waveform after Event
415 BinIn CAPT.TIME Oscillographic Fault
Records
0.10..5.00 sec 0.50 sec Capture Time via Binary Input
610 FltDisp.LED/LCD Device Display Targets on every
Pickup
Display Targets on TRIP
only
Display Targets on every
Pickup
Fault Display on LED / LCD
1103 FullScaleVolt. Power System Data
2
1.0..1200.0 kV 400.0 kV Measurement: Full Scale Voltage
(100%)
1104 FullScaleCurr. Power System Data
2
10..5000 A 1000 A Measurement: Full Scale Current
(100%)
1105 Line Angle Power System Data
2
30..89 ° 85 ° Line Angle
1110 x’ Power System Data
2
0.005..6.500 Ohm / km 0.150 Ohm / km x’ - Line Reactance per length unit
1111 Line Length Power System Data
2
1.0..1000.0 km 100.0 km Line Length
1112 x’ Power System Data
2
0.005..10.000 Ohm / mile 0.242 Ohm / mile x’ - Line Reactance per length unit
1113 Line Length Power System Data
2
0.6..650.0 Miles 62.1 Miles Line Length
1116 RE/RL(Z1) Power System Data
2
-.33..7.00 1.00 Zero seq. comp. factor RE/RL for Z1
1117 XE/XL(Z1) Power System Data
2
-.33..7.00 1.00 Zero seq. comp. factor XE/XL for Z1
1118 RE/RL(Z1B...Z5) Power System Data
2
-.33..7.00 1.00 Zero seq. comp.factor RE/RL for
Z1B...Z5
1119 XE/XL(Z1B...Z5) Power System Data
2
-.33..7.00 1.00 Zero seq. comp.factor XE/XL for
Z1B...Z5
1120 K0 (Z1) Power System Data
2
0.000..4.000 1.000 Zero seq. comp. factor K0 for zone Z1
1121 Angle K0(Z1) Power System Data
2
-135.00..135.00 ° 0.00 ° Zero seq. comp. angle for zone Z1
1122 K0 (> Z1) Power System Data
2
0.000..4.000 1.000 Zero seq.comp.factor K0,higher zones
>Z1
1123 AngleI K0(> Z1) Power System Data
2
-135.00..135.00 ° 0.00 ° Zero seq. comp. angle, higher zones
>Z1
1126 RM/RL ParalLine Power System Data
2
0.00..8.00 0.00 Mutual Parallel Line comp. ratio RM/
RL
1127 XM/XL ParalLine Power System Data
2
0.00..8.00 0.00 Mutual Parallel Line comp. ratio XM/XL
1128 RATIO Par. Comp Power System Data
2
50..95 % 85 % Neutral current RATIO Parallel Line
Comp
Addr. Setting Title Function Setting Options Default Setting Comments
