Appendix
B-11
7SA522 Manual
C53000-G1176-C119-2
3112 T 3I0>>> Earth fault overcur-
rent
0.00..30.00 sec 0.30 sec T 3I0>>> Time delay
3113 3I0>>> Telep/BI Earth fault overcur-
rent
NO
YES
NO Instantaneous trip via Teleprot./BI
3114 3I0>>>SOTF-Trip Earth fault overcur-
rent
NO
YES
NO Instantaneous trip after SwitchOnTo-
Fault
3115 3I0>>>InrushBlk Earth fault overcur-
rent
NO
YES
NO Inrush Blocking
3120 Op. mode 3I0>> Earth fault overcur-
rent
Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode
3121 3I0>> Earth fault overcur-
rent
0.20..25.00 A 2.00 A 3I0>> Pickup
3122 T 3I0>> Earth fault overcur-
rent
0.00..30.00 sec 0.60 sec T 3I0>> Time Delay
3123 3I0>> Telep/BI Earth fault overcur-
rent
NO
YES
NO Instantaneous trip via Teleprot./BI
3124 3I0>> SOTF-Trip Earth fault overcur-
rent
NO
YES
NO Instantaneous trip after SwitchOnTo-
Fault
3125 3I0>> InrushBlk Earth fault overcur-
rent
NO
YES
NO Inrush Blocking
3130 Op. mode 3I0> Earth fault overcur-
rent
Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode
3131 3I0> Earth fault overcur-
rent
0.05..25.00 A 1.00 A 3I0> Pickup
3131 3I0> Earth fault overcur-
rent
0.003..25.000 A 1.000 A 3I0> Pickup
3132 T 3I0> Earth fault overcur-
rent
0.00..30.00 sec 0.90 sec T 3I0> Time Delay
3133 3I0> Telep/BI Earth fault overcur-
rent
NO
YES
NO Instantaneous trip via Teleprot./BI
3134 3I0> SOTF-Trip Earth fault overcur-
rent
NO
YES
NO Instantaneous trip after SwitchOnTo-
Fault
3135 3I0> InrushBlk Earth fault overcur-
rent
NO
YES
NO Inrush Blocking
3140 Op. mode 3I0p Earth fault overcur-
rent
Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode
3141 3I0p PICKUP Earth fault overcur-
rent
0.05..25.00 A 1.00 A 3I0p Pickup
3141 3I0p PICKUP Earth fault overcur-
rent
0.003..25.000 A 1.000 A 3I0p Pickup
3142 3I0p MinT-DELAY Earth fault overcur-
rent
0.00..30.00 sec 1.20 sec 3I0p Minimum Time Delay
3143 3I0p Time Dial Earth fault overcur-
rent
0.05..3.00 sec 0.50 sec 3I0p Time Dial
3144 3I0p Time Dial Earth fault overcur-
rent
0.50..15.00 5.00 3I0p Time Dial
3145 3I0p Time Dial Earth fault overcur-
rent
0.05..15.00 sec 1.35 sec 3I0p Time Dial
3146 3I0p MaxT-DELAY Earth fault overcur-
rent
0.00..30.00 sec 5.80 sec 3I0p Maximum Time Delay
3147 Add.T-DELAY Earth fault overcur-
rent
0.00..30.00 sec 1.20 sec Additional Time Delay
Addr. Setting Title Function Setting Options Default Setting Comments
