Siemens siprotec 7SA6 User Manual

Configuration
5-7
7SA6 Manual
C53000-G1176-C156-2
131 Earth Fault O/C Disabled
Time Overcurrent Curve IEC
Time Overcurrent Curve
ANSI
Time Overcurrent Curve
Logarithmic
Definite Time
U0 inverse
Disabled Earth fault overcurrent
132 Teleprot. E/F Directional Comparison Pik-
kup
PUTT over Protection Inter-
face
Unblocking
Blocking
Disabled
Disabled Teleprotection for Earth fault
overcurr.
133 Auto Reclose 1 AR-cycle
2 AR-cycles
3 AR-cycles
4 AR-cycles
5 AR-cycles
6 AR-cycles
7 AR-cycles
8 AR-cycles
Adaptive Dead Time (ADT)
Disabled
Disabled Auto-Reclose Function
134 AR control mode with Pickup and Action time
with Pickup but without
Action time
with Trip and Action time
with Trip but without Action
time
with Trip and
Action time
Auto-Reclose control mode
135 Synchro-Check Disabled
Enabled
Disabled Synchronism and Voltage Check
137 U/O VOLTAGE Disabled
Enabled
Disabled Under / Overvoltage Protection
138 Fault Locator Enabled
Disabled
with BCD-output
Enabled Fault Locator
139 BREAKER
FAILURE
Disabled
Enabled
Disabled Breaker Failure Protection
140 Trip Cir. Sup. Disabled
1tripcircuit
2tripcircuits
3tripcircuits
Disabled Trip Circuit Supervision
142 Ther. OVERLOAD Disabled
Enabled
Disabled Thermal overload protection
145 P. INTERFACE 1 Enabled
Disabled
Enabled Protection Interface 1 (Port D)
147 NUMBER OF
RELAY
2relays
3relays
2 relays Number of relays
Addr. Setting Title Setting Options Default Setting Comments
