Configuration
5-8
7SA6 Manual
C53000-G1176-C156-2
150 AnalogOutput B1 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Fault location d [miles]
Trip current Imax [primary]
Disabled Analog Output B1 (Port B)
151 AnalogOutput B2 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Fault location d [miles]
Trip current Imax [primary]
Disabled Analog Output B2 (Port B)
152 AnalogOutput D1 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Fault location d [miles]
Trip current Imax [primary]
Disabled Analog Output D1 (Port D)
153 AnalogOutput D2 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Fault location d [miles]
Trip current Imax [primary]
Disabled Analog Output D2 (Port D)
