Hardware and Connections
2-5
7SA6 Manual
C53000-G1176-C156-2
View of Front Panel
with Four-Line
Display
(Housing Size
1
/
2
)
The significance of the operating and display elements is the same as explained after
Figure 2-1. However, 14 LEDs are freely configurable.
Figure 2-2 Front view of a 7SA61, housing size
1
/
2
, for panel flush mounting or cubicle
mounting
SIEMENS
SIPROTEC
1 2
6
3
+/-0
54
7 8 9
7SA611
RUN ERROR
MENU
ESC
LED
ENTER
F4
F1
F2
F3
Meas. Val.
MAIN MENU 01/04
Annunciation
Measurement
Annunciation
Trip log
1
2
