Hardware and Connections
2-6
7SA6 Manual
C53000-G1176-C156-2
View of Front Panel
with Four-Line
Display
(Housing Size
1
/
1
)
Figure 2-3 Front view of a 7SA61, housing size
1
/
1
, for panel flush mounting or cubicle
mounting
SIEMENS
SIPROTEC
1 2
6
3
+/-0
54
7 8 9
7SA6
RUN ERROR
MENU
ESC
LED
ENTER
F4
F1
F2
F3
MAIN MENU 01/04
Annunciation 1
Measurement 2
Annunciation
Meas. Val.
Trip log
The significance of the operating and display elements is the same as explained
after Figure 2-1. However, 14 LEDs are freely configurable.
