Functions

6-316 7SA6 Manual

C53000-G1176-C156-2

Set Points

863 UL3EMin= U L3E Minimum

864 UL3EMax= U L3E Maximum

865 UL12Min= U L12 Minimum

867 UL12Max= U L12 Maximum

868 UL23Min= U L23 Minimum

869 UL23Max= U L23 Maximum

870 UL31Min= U L31 Minimum

871 UL31Min= U L31 Maximum

10102 3U0min = Min. Zero Sequence Voltage 3U0

10103 3U0max = Max. Zero Sequence Voltage 3U0

874 U1 Min = U1 (positive sequence) Voltage Minimum

875 U1 Max = U1 (positive sequence) Voltage Maximum

1040 Pmin Forw= Active Power Minimum Forward

1041 Pmax Forw= Active Power Maximum Forward

1042 Pmin Rev = Active Power Minimum Reverse

1043 Pmax Rev = Active Power Maximum Reverse

1044 Qmin Forw= Reactive Power Minimum Forward

1045 Qmax Forw= Reactive Power Maximum Forward

1046 Qmin Rev = Reactive Power Minimum Reverse

1047 Qmax Rev = Reactive Power Maximum Reverse

880 SMin= Apparent Power Minimum

881 SMax= Apparent Power Maximum

882 fMin= Frequency Minimum

883 fMax= Frequency Maximum

1048 PFminForw= Power Factor Minimum Forward

1049 PFmaxForw= Power Factor Maximum Forward

1050 PFmin Rev= Power Factor Minimum Reverse

1051 PFmax Rev= Power Factor Maximum Reverse

F.No. Alarm Comments

IL1dmd> Upper setting limit for IL1dmd

IL2dmd> Upper setting limit for IL2dmd

IL3dmd> Upper setting limit for IL3dmd

I1dmd> Upper setting limit for I1dmd

|Pdmd|> Upper setting limit for Pdmd
