Functions
6-3177SA6 Manual
C53000-G1176-C156-2
Waveform Capture
|Qdmd|> Upper setting limit for Qdmd
Sdmd> Upper setting limit for Sdmd
273 SP. IL1 dmd> Set Point Phase L1 dmd>
274 SP. IL2 dmd> Set Point Phase L2 dmd>
275 SP. IL3 dmd> Set Point Phase L3 dmd>
276 SP. I1dmd> Set Point positive sequence I1dmd>
277 SP. |Pdmd|> Set Point |Pdmd|>
278 SP. |Qdmd|> Set Point |Qdmd|>
279 SP. |Sdmd|> Set Point |Sdmd|>
PF< Lower setting limit for Power Factor
285 cosϕ alarm Power factor alarm
F.No. Alarm Comments
F.No. Alarm Comments
4 >Trig.Wave.Cap. >Trigger Waveform Capture
203 Wave. deleted Waveform data deleted
FltRecSta Fault Recording Start
