• cos ϕ Pos, cos ϕ Neg: power factor separately according Demand Forward and
Demand Reverse;
• f: frequency.
From the
DeviceFront
With a device ready for operation, first press the key. The MAIN MENU appears.
Use the key to select the menu item
Measurement,andswitchtothelistofmeas-
ured values using the key. The
MEASUREMENT selection appears. See Figure 7-19.
.
Figure 7-19 Selection of measured values on the front — example
The measured values are divided into the following groups:
01
Operation. pri Operational measured values, primary.
03
Impedance Prim Operational impedance, primary;
04
SynchrCheck,pri Measured values of synchronism check, primary;
11
Operation. sec Operational measured values, secondary;
12
IEE,secondary Measured values of earth fault, secondary;
13
Impedance Sec Operational impedance, secondary ;
21
Percent Operational measured values, in percent of operational
nominal quantities;
31
Demand Long-term average values, in primary values;
32
Min/Max Demand Minimum and maximum average values with date and time
indication of moment of occurrence, in primary values;
33
U/I,Min/Max Minimum and maximum values of voltages and currents
with date and time indication of moment of occurrence, in
primary values;
34
p,cosϕ,Min/Max Minimum and maximum values of the actve, reactive and
apparent power of the frequence and the power factor;
41
Thermal Meter Thermal measured values of the overload protection, if
available;
51
User Defined Measured values that are defined by the user during initial
setting of the device (see Section 5.2).
61
Set Points See Subsubsection 7.1.3.2
71
Set points (MV) See Subsubsection 7.1.3.3
81
Reset See Subsubsection 7.1.3.4.
MENU
Etc.
MAIN MENU 02/05
---------------------
Annunciation –> 1
>Measurement –> 2
MEASUREMENT 01/12
--------------------
>Operation. pri 01
>Operation. sec 02
To Next Page
