Technical Data
10-8 7SA6 Manual
C53000-G1176-C156
– Test voltage 500 V; 50 Hz
– Transmission speed up to 12 MBd
– Maximum transmission distance 1000 m at
≤ 93.75 kBd
500 m at
≤ 187.5 kBd
200 m at
≤ 1.5 MBd
100 m at
≤ 12 MBd
Optical fibre
– Connector Type ST–connector
for flush mounted case rear panel, mounting location “B”
for surface mounted case at the inclined housing on the case bottom
– Optical wavelength
λ =820nm
– Laser class 1 acc. EN 60825–1/ –2 using glass fibre 50/125 µm or
usingglassfibre62.5/125µm
– Permissible optical signal attenuation max. 8 dB, using glass fibre 62.5/125 µm
– Maximum transmission distance 1.5 km (0.93 miles)
– Character idle state selectable; factory setting: “Light off”
Profibus Optical
– Connector Type ST–plug
single ring or twin ring depending on
ordered version
– Connection for flush mounted case rear panel, mounting location “B”
for surface mounted case please use the relay with Profibus RS485
interface and separate fibre optic converter.
– Transmission speed to 1.5 MBd
recommended: > 500 kBd
– Optical wavelength
λ =820nm
– Laser class 1 acc. EN 60825–1/ –2 using glass fibre 50/125 µm or
usingglassfibre62.5/125µm
– Permissible optical signal attenuation max. 8 dB using glass fibre 62.5/125 µm
– Maximum transmission distance 1500 m (4920 ft)
Time
Synchronization
Interface
– Signal type DCF77/IRIG B-Signal
– Connection for flush mounted case rear panel, mounting location “A”
9-pin DSUB socket
for surface mounted case at the terminal on the case bottom
– Nominal signal voltages optional 5 V, 12 V or 24 V
– Signal level and burden:
Nominal signal input voltage
5V 12V 24V
U
IHigh
6.0 V 15.8 V 31 V
U
ILow
1.0 V for I
ILow
= 0.25 mA 1.4 V for I
ILow
= 0.25 mA 1.9 V for I
ILow
=0.25mA
I
IHigh
4.5mAto9.4mA 4.5mAto9.3mA 4.5mAto8.7mA
R
I
890 Ω for U
I
=4V
640 Ω
forU
I
=6V
1930 Ω
for U
I
=8.7V
1700 Ω
for U
I
= 15.8 V
3780 Ω
for U
I
=17V
3560 Ω
for U
I
=31V
