Appendix
B-16
7SA6 Manual
C53000-G1176-C156-2
3430 AR TRIP 3pole Automatic Reclo-
sure
YES
NO
YES 3pole TRIP by AR
3431 DLC or RDT Automatic Reclo-
sure
Without
Reduced Dead Time (RDT)
Dead Line Check (DLC)
Without Dead Line Check or Reduced Dead
Time
3433 T-ACTION ADT Automatic Reclo-
sure
0.01..300.00 sec; ∞ 0.20 sec Action time
3434 T-MAX ADT Automatic Reclo-
sure
0.50..3000.00 sec 5.00 sec Maximum dead time
3435 ADT 1p allowed Automatic Reclo-
sure
YES
NO
NO 1pole TRIP allowed
3436 ADT CB? CLOSE Automatic Reclo-
sure
YES
NO
NO CB ready interrogation before reclos-
ing
3437 ADT SynRequest Automatic Reclo-
sure
YES
NO
NO Request for synchro-check after 3pole
AR
3438 T U-stable Automatic Reclo-
sure
0.10..30.00 sec 0.10 sec Supervision time for dead/ live voltage
3440 U-live> Automatic Reclo-
sure
30..90 V 48 V Voltage threshold for live line or bus
3441 U-dead< Automatic Reclo-
sure
2..70 V 30 V Voltage threshold for dead line or bus
3450 1.AR: START Automatic Reclo-
sure
YES
NO
YES Start of AR allowed in this cycle
3451 1.AR: T-ACTION Automatic Reclo-
sure
0.01..300.00 sec; ∞ 0.20 sec Action time
3453 1.AR Tdead 1Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3454 1.AR Tdead 2Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3455 1.AR Tdead 3Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3456 1.AR Tdead1Trip Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 1pole trip
3457 1.AR Tdead3Trip Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3458 1.AR: Tdead EV. Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3459 1.AR: CB? CLOSE Automatic Reclo-
sure
YES
NO
NO CB ready interrogation before reclos-
ing
3460 1.AR SynRequest Automatic Reclo-
sure
YES
NO
NO Request for synchro-check after 3pole
AR
3461 2.AR: START Automatic Reclo-
sure
YES
NO
NO AR start allowed in this cycle
3462 2.AR: T-ACTION Automatic Reclo-
sure
0.01..300.00 sec; ∞ 0.20 sec Action time
3464 2.AR Tdead 1Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3465 2.AR Tdead 2Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3466 2.AR Tdead 3Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3467 2.AR Tdead1Trip Automatic Reclo-
sure
0.01..1800.00 sec; ∞∞sec Dead time after 1pole trip
3468 2.AR Tdead3Trip Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3469 2.AR: Tdead EV. Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after evolving fault
Addr. Setting Title Function Setting Options Default Setting Comments
