Appendix
B-17
7SA6 Manual
C53000-G1176-C156-2
3470 2.AR: CB? CLOSE Automatic Reclo-
sure
YES
NO
NO CB ready interrogation before reclos-
ing
3471 2.AR SynRequest Automatic Reclo-
sure
YES
NO
NO Request for synchro-check after 3pole
AR
3472 3.AR: START Automatic Reclo-
sure
YES
NO
NO AR start allowed in this cycle
3473 3.AR: T-ACTION Automatic Reclo-
sure
0.01..300.00 sec; ∞ 0.20 sec Action time
3475 3.AR Tdead 1Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3476 3.AR Tdead 2Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3477 3.AR Tdead 3Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3478 3.AR Tdead1Trip Automatic Reclo-
sure
0.01..1800.00 sec; ∞∞sec Dead time after 1pole trip
3479 3.AR Tdead3Trip Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3480 3.AR: Tdead EV. Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3481 3.AR: CB? CLOSE Automatic Reclo-
sure
YES
NO
NO CB ready interrogation before reclos-
ing
3482 3.AR SynRequest Automatic Reclo-
sure
YES
NO
NO Request for synchro-check after 3pole
AR
3483 4.AR: START Automatic Reclo-
sure
YES
NO
NO AR start allowed in this cycle
3484 4.AR: T-ACTION Automatic Reclo-
sure
0.01..300.00 sec; ∞ 0.20 sec Action time
3486 4.AR Tdead 1Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3487 4.AR Tdead 2Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3488 4.AR Tdead 3Flt Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3489 4.AR Tdead1Trip Automatic Reclo-
sure
0.01..1800.00 sec; ∞∞sec Dead time after 1pole trip
3490 4.AR Tdead3Trip Automatic Reclo-
sure
0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3491 4.AR: Tdead EV. Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3492 4.AR: CB? CLOSE Automatic Reclo-
sure
YES
NO
NO CB ready interrogation before reclos-
ing
3493 4.AR SynRequest Automatic Reclo-
sure
YES
NO
NO Request for synchro-check after 3pole
AR
3501 FCT Synchronism Synchronism and
Voltage Check
ON
OFF
ON Synchronism and Voltage Check func-
tion
3502 Dead Volt. Thr. Synchronism and
Voltage Check
1..60V 5V Voltagethresholddeadline/bus
3503 Live Volt. Thr. Synchronism and
Voltage Check
20..125 V 90 V Voltage threshold live line / bus
3504 Umax Synchronism and
Voltage Check
20..140 V 110 V Maximum permissible voltage
3507 T-SYN. DURATION Synchronism and
Voltage Check
0.01..600.00 sec; ∞ 1.00 sec Maximum duration of synchronism-
check
3508 T SYNC-STAB Synchronism and
Voltage Check
0.00..30.00 sec 0.00 sec Synchronous condition stability timer
Addr. Setting Title Function Setting Options Default Setting Comments
