Siemens siprotec 7SA6 User Manual

Appendix
B-21
7SA6 Manual
C53000-G1176-C156-2
4505A PROT 1 T-DELAY Protection Interface
(Port D+E)
0.1..30.0 ms 30.0 ms Prot 1: Maximal permissible delay time
4509 T-DATA DISTURB Protection Interface
(Port D+E)
0.05..2.00 sec 0.10 sec Time delay for data disturbance alarm
4510 T-DATAFAIL Protection Interface
(Port D+E)
0.0..60.0 sec 6.0 sec Time del for transmission failure alarm
4511 Td ResetRemote Protection Interface
(Port D+E)
0.00..300.00 sec; ∞ 0.00 sec Remote signal RESET DELAY for
comm.fail
4701 ID OF RELAY 1 Protection Interface
(Port D+E)
1..65534 1 Identification number of relay 1
4702 ID OF RELAY 2 Protection Interface
(Port D+E)
1..65534 2 Identification number of relay 2
4703 ID OF RELAY 3 Protection Interface
(Port D+E)
1..65534 3 Identification number of relay 3
4710 LOCAL RELAY Protection Interface
(Port D+E)
relay 1
relay 2
relay 3
relay 1 Local relay is
5001 20 mA (B1) = AnalogOutputs 10.0..1000.0 % 200.0 % 20 mA (B1) correspond to
5002 20 mA (B1) = AnalogOutputs 10..100000 A 20000 A 20 mA (B1) correspond to
5003 20 mA (B1) = AnalogOutputs 1.0..1000.0 km 50.0 km 20 mA (B1) correspond to
5004 20 mA (B1) = AnalogOutputs 1.0..1000.0 Miles 50.0 Miles 20 mA (B1) correspond to
5006 MIN VALUE (B1) AnalogOutputs 0.0..5.0 mA 4.0 mA Output value (B1) valid from
5007 NEG VALUE (B1) AnalogOutputs 1.00..22.50 mA 19.84 mA Output value (B1) for negative values
5008 OVERFLOW (B1) AnalogOutputs 1.00..22.50 mA 22.50 mA Output value (B1) for overflow
5009 Tmax OUTPUT(B1) AnalogOutputs 0.10..180.00 sec; ∞ 5.00 sec Maximum output time (B1)
5011 20 mA (B2) = AnalogOutputs 10.0..1000.0 % 200.0 % 20 mA (B2) correspond to
5012 20 mA (B2) = AnalogOutputs 10..100000 A 20000 A 20 mA (B2) correspond to
5013 20 mA (B2) = AnalogOutputs 1.0..1000.0 km 50.0 km 20 mA (B2) correspond to
5014 20 mA (B2) = AnalogOutputs 1.0..1000.0 Miles 50.0 Miles 20 mA (B2) correspond to
5016 MIN VALUE (B2) AnalogOutputs 0.0..5.0 mA 4.0 mA Output value (B2) valid from
5017 NEG VALUE (B2) AnalogOutputs 1.00..22.50 mA 19.84 mA Output value (B2) for negative values
5018 OVERFLOW (B2) AnalogOutputs 1.00..22.50 mA 22.50 mA Output value (B2) for overflow
5019 Tmax OUTPUT(B2) AnalogOutputs 0.10..180.00 sec; ∞ 5.00 sec Maximum output time (B2)
5021 20 mA (D1) = AnalogOutputs 10.0..1000.0 % 200.0 % 20 mA (D1) correspond to
5022 20 mA (D1) = AnalogOutputs 10..100000 A 20000 A 20 mA (D1) correspond to
5023 20 mA (D1) = AnalogOutputs 1.0..1000.0 km 50.0 km 20 mA (D1) correspond to
5024 20 mA (D1) = AnalogOutputs 1.0..1000.0 Miles 50.0 Miles 20 mA (D1) correspond to
5026 MIN VALUE (D1) AnalogOutputs 0.0..5.0 mA 4.0 mA Output value (D1) valid from
5027 NEG VALUE (D1) AnalogOutputs 1.00..22.50 mA 19.84 mA Output value (D1) for negative values
5028 OVERFLOW (D1) AnalogOutputs 1.00..22.50 mA 22.50 mA Output value (D1) for overflow
5029 Tmax OUTPUT(D1) AnalogOutputs 0.10..180.00 sec; ∞ 5.00 sec Maximum output time (D1)
5031 20 mA (D2) = AnalogOutputs 10.0..1000.0 % 200.0 % 20 mA (D2) correspond to
5032 20 mA (D2) = AnalogOutputs 10..100000 A 20000 A 20 mA (D2) correspond to
5033 20 mA (D2) = AnalogOutputs 1.0..1000.0 km 50.0 km 20 mA (D2) correspond to
5034 20 mA (D2) = AnalogOutputs 1.0..1000.0 Miles 50.0 Miles 20 mA (D2) correspond to
5036 MIN VALUE (D2) AnalogOutputs 0.0..5.0 mA 4.0 mA Output value (D2) valid from
5037 NEG VALUE (D2) AnalogOutputs 1.00..22.50 mA 19.84 mA Output value (D2) for negative values
5038 OVERFLOW (D2) AnalogOutputs 1.00..22.50 mA 22.50 mA Output value (D2) for overflow
Addr. Setting Title Function Setting Options Default Setting Comments
