Appendix
B-22
7SA6 Manual
C53000-G1176-C156-2
"Note": Depending on the version and the variant ordered some addresses are not used or have different
default settings. The setting ranges and presettings listed in the table refer to a nominal current value I
N
= 1 A. For a secondary nominal current value I
N
= 5 A the current values are to be multiplied by 5. For
setting primary values the transformation ratio of the transformer also must be taken into consideration.
Settings specified with an "A" can only be changed with
DIGSI
®
4 under "Additional Settings".
5039 Tmax OUTPUT(D2) AnalogOutputs 0.10..180.00 sec; ∞ 5.00 sec Maximum output time (D2)
Addr. Setting Title Function Setting Options Default Setting Comments
