Appendix
B-24
7SA6 Manual
C53000-G1176-C156-2
71 Settings Check (Settings Check) Device OUT * * LED BO
72 Level-2 change (Level-2 change) Device OUT ON
OFF
* LED BO
73 Local setting change (Local change) Device OUT * *
110 Event lost (Event Lost) Device OUT_Ev ON * LED BO 135 130 1
113 Flag Lost (Flag Lost) Device OUT ON * M LED BO 135 136 1 GI
125 Chatter ON (Chatter ON) Device OUT ON
OFF
* LED BO 135 145 1 GI
126 Protection ON/OFF (via system port) (Pro-
tON/OFF)
Device IntSP ON
OFF
* LED BO
127 Auto Reclose ON/OFF (via system port)
(AR ON/OFF)
Device IntSP ON
OFF
* LED BO
128 Teleprot. ON/OFF (via system port) (Tele-
pONoff)
Device IntSP ON
OFF
* LED BO
140 Error with a summary alarm (Error Sum
Alarm)
Device OUT ON
OFF
* LED BO 128 47 1 GI
144 Error 5V (Error 5V) Device OUT ON
OFF
* LED BO 135 164 1 GI
160 Alarm Summary Event (Alarm Sum Event) Device OUT * * LED BO 128 46 1 GI
161 Failure: General Current Supervision (Fail
I Superv.)
Measurement
Supervision
OUT * * LED BO 128 32 1 GI
162 Failure: Current Summation (Failure Σ I) Measurement
Supervision
OUT ON
OFF
* LED BO 135 182 1 GI
163 Failure: Current Balance (Fail I balance) Measurement
Supervision
OUT ON
OFF
* LED BO 135 183 1 GI
164 Failure: general Voltage Supervision (Fail
U Superv.)
Measurement
Supervision
OUT * * LED BO 128 33 1 GI
165 Failure: Voltage summation Phase-Earth
(Fail Σ UPh-E)
Measurement
Supervision
OUT ON
OFF
* LED BO 135 184 1 GI
167 Failure: Voltage Balance (Fail U balance) Measurement
Supervision
OUT ON
OFF
* LED BO 135 186 1 GI
168 Failure: Voltage absent (Fail U absent) Measurement
Supervision
OUT ON
OFF
* LED BO 135 187 1 GI
169 VT Fuse Failure (alarm >10s) (VT Fuse-
Fail>10s)
Measurement
Supervision
OUT ON
OFF
* LED BO 135 188 1 GI
170 VT Fuse Failure (alarm instantaneous) (VT
FuseFail)
Measurement
Supervision
OUT ON
OFF
* LED BO
171 Failure: Phase Sequence (Fail Ph. Seq.) Measurement
Supervision
OUT ON
OFF
* LED BO 128 35 1 GI
177 Failure: Battery empty (Fail Battery) Device OUT ON
OFF
* LED BO 135 193 1 GI
181 Error: A/D converter (Error A/D-conv.) Device OUT ON
OFF
* LED BO 135 178 1 GI
182 Alarm: Real Time Clock (Alarm Clock) Device OUT ON
OFF
* LED BO 135 194 1 GI
183 Error Board 1 (Error Board 1) Device OUT ON
OFF
* LED BO 135 171 1 GI
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
To Next Page
