Appendix
B-25
7SA6 Manual
C53000-G1176-C156-2
184 Error Board 2 (Error Board 2) Device OUT ON
OFF
* LED BO 135 172 1 GI
185 Error Board 3 (Error Board 3) Device OUT ON
OFF
* LED BO 135 173 1 GI
186 Error Board 4 (Error Board 4) Device OUT ON
OFF
* LED BO 135 174 1 GI
187 Error Board 5 (Error Board 5) Device OUT ON
OFF
* LED BO 135 175 1 GI
188 Error Board 6 (Error Board 6) Device OUT ON
OFF
* LED BO 135 176 1 GI
189 Error Board 7 (Error Board 7) Device OUT ON
OFF
* LED BO 135 177 1 GI
190 Error Board 0 (Error Board 0) Device OUT ON
OFF
* LED BO 135 210 1 GI
192 Error:1A/5Ajumper different from setting
(Error1A/5Awrong)
Device OUT ON
OFF
* LED BO 135 169 1 GI
193 Alarm: NO calibration data available
(Alarm NO calibr)
Device OUT ON
OFF
* LED BO 135 181 1 GI
194 Error: Neutral CT different from MLFB
(Error neutralCT)
Device OUT ON
OFF
* LED BO 135 180 1 GI
195 Failure: Broken Conductor (Fail Conduc-
tor)
Measurement
Supervision
OUT ON
OFF
* LED BO 135 195 1 GI
196 Fuse Fail Monitor is switched OFF (Fuse
Fail M.OFF)
Measurement
Supervision
OUT ON
OFF
* LED BO 135 196 1 GI
197 Measurement Supervision is switched
OFF (MeasSup OFF)
Measurement
Supervision
OUT ON
OFF
* LED BO 135 197 1 GI
203 Waveform data deleted (Wave. deleted) Oscillographic
Fault Records
OUT_Ev ON * LED BO 135 203 1
273 Set Point Phase L1 dmd> (SP. IL1 dmd>) Set Points (Mea-
sured Values)
OUT on
off
* LED BO 135 230 1 GI
274 Set Point Phase L2 dmd> (SP. IL2 dmd>) Set Points (Mea-
sured Values)
OUT on
off
* LED BO 135 234 1 GI
275 Set Point Phase L3 dmd> (SP. IL3 dmd>) Set Points (Mea-
sured Values)
OUT on
off
* LED BO 135 235 1 GI
276 Set Point positive sequence I1dmd> (SP.
I1dmd>)
Set Points (Mea-
sured Values)
OUT on
off
* LED BO 135 236 1 GI
277 Set Point |Pdmd|> (SP. |Pdmd|>) Set Points (Mea-
sured Values)
OUT on
off
* LED BO 135 237 1 GI
278 Set Point |Qdmd|> (SP. |Qdmd|>) Set Points (Mea-
sured Values)
OUT on
off
* LED BO 135 238 1 GI
279 Set Point |Sdmd|> (SP. |Sdmd|>) Set Points (Mea-
sured Values)
OUT on
off
* LED BO 135 239 1 GI
285 Power factor alarm (cosϕ alarm) Set Points (Mea-
sured Values)
OUT on
off
* LED BO 135 245 1 GI
351 >Circuit breaker aux. contact: Pole L1
(>CB Aux. L1)
Power System
Data 2
SP * * LED BI BO 150 1 1 GI
352 >Circuit breaker aux. contact: Pole L2
(>CB Aux. L2)
Power System
Data 2
SP * * LED BI BO 150 2 1 GI
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
