Siemens siprotec 7SA6 User Manual

Appendix
B-30
7SA6 Manual
C53000-G1176-C156-2
1253 >Block sensitive E/F detection (>SensEF
block)
Sensitive Earth
Flt.(comp/ isol.
starp.)
SP * * LED BI BO
1260 Sensitve E/F detection ON/OFF via BI
(SensEF on/offBI)
Sensitive Earth
Flt.(comp/ isol.
starp.)
IntSP ON
OFF
* LED BO
1261 Sensitve E/F detection is switched OFF
(SensEF OFF)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT ON
OFF
* LED BO 151 161 1 GI
1262 Sensitve E/F detection is BLOCKED
(SensEF BLOCK)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT ON
OFF
ON
OFF
LED BO 151 162 1 GI
1263 Sensitve E/F detection is ACTIVE
(SensEF ACTIVE)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT ON
OFF
* LED BO 151 163 1 GI
1271 Sensitve E/F detection picked up (SensEF
Pickup)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * ON
OFF
*MLED BO
1272 Sensitve E/F detection Phase L1 (SensEF
Phase L1)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * * ON LED BO 128 48 1 GI
1273 Sensitve E/F detection Phase L2 (SensEF
Phase L2)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * * ON LED BO 128 49 1 GI
1274 Sensitve E/F detection Phase L3 (SensEF
Phase L3)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * * ON LED BO 128 50 1 GI
1276 Sensitve E/F detection Forward (SensEF
Forward)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * * ON LED BO 128 51 1 GI
1277 Sensitve E/F detection Reverse (SensEF
Reverse)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * * ON LED BO 128 52 1 GI
1278 Sensitve E/F detection Undef. Direction
(SensEF undefDir)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * * ON LED BO 151 178 1 GI
1281 Sensitve E/F detection TRIP command
(SensEF TRIP)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * ON ON LED BO 151 181 2 GI
1291 Sensitve E/F detection 3U0> pickup
(SensEF 3U0>)
Sensitive Earth
Flt.(comp/ isol.
starp.)
OUT * * LED BO
1305 >Earth Fault O/C Block 3I0>>> (>EF BLK
3I0>>>)
Earth fault over-
current
SP ON
OFF
* LED BI BO 166 5 1 GI
1307 >Earth Fault O/C Block 3I0>> (>EF
BLOCK 3I0>>)
Earth fault over-
current
SP ON
OFF
* LED BI BO 166 7 1 GI
1308 >Earth Fault O/C Block 3I0> (>EF BLOCK
3I0>)
Earth fault over-
current
SP ON
OFF
* LED BI BO 166 8 1 GI
1309 >Earth Fault O/C Block 3I0p (>EF BLOCK
3I0p)
Earth fault over-
current
SP ON
OFF
* LED BI BO 166 9 1 GI
1310 >Earth Fault O/C Instantaneous trip (>EF
InstTRIP)
Earth fault over-
current
SP ON
OFF
ON
OFF
LED BI BO 166 10 1 GI
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off Trip (Fault) Log On/Off Ground Fault Log On/Off Marked in Oscill. Record LED Binary Input Function Key Binary Output Chatter Blocking Type Information-No Data Unit (ASDU) General Interrogation
