Siemens siprotec 7SA6 User Manual

Appendix
B-31
7SA6 Manual
C53000-G1176-C156-2
1311 >E/F Teleprotection ON (>EF Tele-
prot.ON)
Teleprotection for
Earth fault over-
curr.
SP * * LED BI BO
1312 >E/F Teleprotection OFF (>EF Teleprot-
OFF)
Teleprotection for
Earth fault over-
curr.
SP * * LED BI BO
1313 >E/F Teleprotection BLOCK (>EF Tele-
protBLK)
Teleprotection for
Earth fault over-
curr.
SP ON
OFF
* LED BI BO 166 13 1 GI
1318 >E/F Carrier RECEPTION, Channel 1
(>EF Rec.Ch1)
Teleprotection for
Earth fault over-
curr.
SP on
off
on LED BI BO 166 18 1 GI
1319 >E/F Carrier RECEPTION, Channel 2
(>EF Rec.Ch2)
Teleprotection for
Earth fault over-
curr.
SP on
off
on LED BI BO 166 19 1 GI
1320 >E/F Unblocking: UNBLOCK, Channel 1
(>EF UB ub 1)
Teleprotection for
Earth fault over-
curr.
SP ON
OFF
ON LED BI BO 166 20 1 GI
1321 >E/F Unblocking: BLOCK, Channel 1 (>EF
UB bl 1)
Teleprotection for
Earth fault over-
curr.
SP ON
OFF
ON LED BI BO 166 21 1 GI
1322 >E/F Unblocking: UNBLOCK, Channel 2
(>EF UB ub 2)
Teleprotection for
Earth fault over-
curr.
SP ON
OFF
ON LED BI BO 166 22 1 GI
1323 >E/F Unblocking: BLOCK, Channel 2 (>EF
UB bl 2)
Teleprotection for
Earth fault over-
curr.
SP ON
OFF
ON LED BI BO 166 23 1 GI
1324 >E/F BLOCK Echo Signal (>EF BlkEcho) Teleprotection for
Earth fault over-
curr.
SP ON
OFF
ON LED BI BO 166 24 1 GI
1331 Earth fault protection is switched OFF (E/F
Prot. OFF)
Earth fault over-
current
OUT ON
OFF
* LED BO 166 31 1 GI
1332 Earth fault protection is BLOCKED (E/F
BLOCK)
Earth fault over-
current
OUT ON
OFF
ON
OFF
LED BO 166 32 1 GI
1333 Earth fault protection is ACTIVE (E/F
ACTIVE)
Earth fault over-
current
OUT * * LED BO 166 33 1 GI
1345 Earth fault protection PICKED UP (EF
Pickup)
Earth fault over-
current
OUT *
OFF
M LED BO 166 45 2 GI
1354 E/F 3I0>>> PICKED UP (EF
3I0>>>Pickup)
Earth fault over-
current
OUT * ON LED BO
1355 E/F 3I0>> PICKED UP (EF 3I0>> Pikkup) Earth fault over-
current
OUT * ON LED BO
1356 E/F 3I0> PICKED UP (EF 3I0> Pikkup) Earth fault over-
current
OUT * ON LED BO
1357 E/F 3I0p PICKED UP (EF 3I0p Pikkup) Earth fault over-
current
OUT * ON LED BO
1358 E/F picked up FORWARD (EF forward) Earth fault over-
current
OUT * ON LED BO 166 58 2
1359 E/F picked up REVERSE (EF reverse) Earth fault over-
current
OUT * ON LED BO 166 59 2
1361 E/F General TRIP command (EF Trip) Earth fault over-
current
OUT * * LED BO 166 61 2
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off Trip (Fault) Log On/Off Ground Fault Log On/Off Marked in Oscill. Record LED Binary Input Function Key Binary Output Chatter Blocking Type Information-No Data Unit (ASDU) General Interrogation
