1366 E/F 3I0>>> TRIP (EF 3I0>>> TRIP) Earth fault over-
current
OUT * ON LED BO 166 66 2
1367 E/F 3I0>> TRIP (EF 3I0>> TRIP) Earth fault over-
current
OUT * ON LED BO 166 67 2
1368 E/F 3I0> TRIP (EF 3I0> TRIP) Earth fault over-
current
OUT * ON LED BO 166 68 2
1369 E/F 3I0p TRIP (EF 3I0p TRIP) Earth fault over-
current
OUT * ON LED BO 166 69 2
1370 E/F Inrush picked up (EF InrushPU) Earth fault over-
current
OUT * ON
OFF
LED BO 166 70 2
1380 E/F Teleprot. ON/OFF via BI (EF TeleON/
offBI)
Teleprotection for
Earth fault over-
curr.
IntSP ON
OFF
* LED BO
1381 E/F Teleprotection is switched OFF (EF
Telep. OFF)
Teleprotection for
Earth fault over-
curr.
OUT ON
OFF
* LED BO 166 81 1 GI
1384 E/F Telep. Carrier SEND signal (EF Tele
SEND)
Teleprotection for
Earth fault over-
curr.
OUT on on LED BO 166 84 2
1386 E/F Telep. Transient Blocking (EF Tele-
TransBlk)
Teleprotection for
Earth fault over-
curr.
OUT * ON LED BO 166 86 2
1387 E/F Telep. Unblocking: FAILURE Channel
1 (EF TeleUB Fail1)
Teleprotection for
Earth fault over-
curr.
OUT ON
OFF
* LED BO 166 87 1 GI
1388 E/F Telep. Unblocking: FAILURE Channel
2 (EF TeleUB Fail2)
Teleprotection for
Earth fault over-
curr.
OUT ON
OFF
* LED BO 166 88 1 GI
1389 E/F Telep. Blocking: carrier STOP signal
(EF Tele BL STOP)
Teleprotection for
Earth fault over-
curr.
OUT * on LED BO 166 89 2
1390 E/F Tele.Blocking: Send signal with jump
(EF Tele BL Jump)
Teleprotection for
Earth fault over-
curr.
OUT * * LED BO 166 90 2
1391 EF Tele.Carrier RECEPTION, L1, Device1
(EF Rec.L1 Dev1)
Teleprotection for
Earth fault over-
curr.
OUT on
off
on LED BO
1392 EF Tele.Carrier RECEPTION, L2, Device1
(EF Rec.L2 Dev1)
Teleprotection for
Earth fault over-
curr.
OUT on
off
on LED BO
1393 EF Tele.Carrier RECEPTION, L3, Device1
(EF Rec.L3 Dev1)
Teleprotection for
Earth fault over-
curr.
OUT on
off
on LED BO
1394 EF Tele.Carrier RECEPTION, L1, Device2
(EF Rec.L1 Dev2)
Teleprotection for
Earth fault over-
curr.
OUT on
off
on LED BO
1395 EF Tele.Carrier RECEPTION, L2, Device2
(EF Rec.L2 Dev2)
Teleprotection for
Earth fault over-
curr.
OUT on
off
on LED BO
1396 EF Tele.Carrier RECEPTION, L3, Device2
(EF Rec.L3 Dev2)
Teleprotection for
Earth fault over-
curr.
OUT on
off
on LED BO
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off Trip (Fault) Log On/Off Ground Fault Log On/Off Marked in Oscill. Record LED Binary Input Function Key Binary Output Chatter Blocking Type Information-No Data Unit (ASDU) General Interrogation
