Appendix
B-52
7SA6 Manual
C53000-G1176-C156-2
7172 Backup O/C Pickup - Only L1 (O/C PU 1p.
L1)
Backup overcur-
rent
OUT * ON LED BO 64722
7173 Backup O/C Pickup L1E (O/C Pickup L1E) Backup overcur-
rent
OUT * ON LED BO 64732
7174 Backup O/C Pickup - Only L2 (O/C PU 1p.
L2)
Backup overcur-
rent
OUT * ON LED BO 64742
7175 Backup O/C Pickup L2E (O/C Pickup L2E) Backup overcur-
rent
OUT * ON LED BO 64752
7176 Backup O/C Pickup L12 (O/C Pickup L12) Backup overcur-
rent
OUT * ON LED BO 64762
7177 Backup O/C Pickup L12E (O/C Pickup
L12E)
Backup overcur-
rent
OUT * ON LED BO 64772
7178 Backup O/C Pickup - Only L3 (O/C PU 1p.
L3)
Backup overcur-
rent
OUT * ON LED BO 64782
7179 Backup O/C Pickup L3E (O/C Pickup L3E) Backup overcur-
rent
OUT * ON LED BO 64792
7180 Backup O/C Pickup L31 (O/C Pickup L31) Backup overcur-
rent
OUT * ON LED BO 64802
7181 Backup O/C Pickup L31E (O/C Pickup
L31E)
Backup overcur-
rent
OUT * ON LED BO 64812
7182 Backup O/C Pickup L23 (O/C Pickup L23) Backup overcur-
rent
OUT * ON LED BO 64822
7183 Backup O/C Pickup L23E (O/C Pickup
L23E)
Backup overcur-
rent
OUT * ON LED BO 64832
7184 Backup O/C Pickup L123 (O/C Pickup
L123)
Backup overcur-
rent
OUT * ON LED BO 64842
7185 Backup O/C Pickup L123E (O/C
PickupL123E)
Backup overcur-
rent
OUT * ON LED BO 64852
7191 Backup O/C Pickup I>> (O/C PICKUP I>>) Backup overcur-
rent
OUT * ON LED BO 64912 GI
7192 Backup O/C Pickup I> (O/C PICKUP I>) Backup overcur-
rent
OUT * ON LED BO 64922 GI
7193 Backup O/C Pickup Ip (O/C PICKUP Ip) Backup overcur-
rent
OUT * ON LED BO 64932 GI
7201 O/C I-STUB Pickup (I-STUB PICKUP) Backup overcur-
rent
OUT * ON
OFF
LED BO 64 101 2 GI
7211 Backup O/C General TRIP command (O/C
TRIP)
Backup overcur-
rent
OUT * * LED BO 128 72 2
7212 Backup O/C TRIP - Only L1 (O/C TRIP
1p.L1)
Backup overcur-
rent
OUT * ON LED BO 64 112 2
7213 Backup O/C TRIP - Only L2 (O/C TRIP
1p.L2)
Backup overcur-
rent
OUT * ON LED BO 64 113 2
7214 Backup O/C TRIP - Only L3 (O/C TRIP
1p.L3)
Backup overcur-
rent
OUT * ON LED BO 64 114 2
7215 Backup O/C TRIP Phases L123 (O/C
TRIP L123)
Backup overcur-
rent
OUT * ON LED BO 64 115 2
7221 Backup O/C TRIP I>> (O/C TRIP I>>) Backup overcur-
rent
OUT * ON LED BO 64 121 2
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
To Next Page
