Appendix
B-54
7SA6 Manual
C53000-G1176-C156-2
10218 Uph-ph>(>) Overvolt. is BLOCKED (Uph-
ph>(>) BLK)
VoltageProtection OUT ON
OFF
ON
OFF
LED BO 73181 GI
10219 3U0>(>) Overvolt. is switched OFF
(3U0>(>) OFF)
VoltageProtection OUT ON
OFF
* LED BO 73 19 1 GI
10220 3U0>(>) Overvolt. is BLOCKED (3U0>(>)
BLK)
VoltageProtection OUT ON
OFF
ON
OFF
LED BO 73201 GI
10221 U1>(>) Overvolt. is switched OFF (U1>(>)
OFF)
VoltageProtection OUT ON
OFF
* LED BO 73 21 1 GI
10222 U1>(>) Overvolt. is BLOCKED (U1>(>)
BLK)
VoltageProtection OUT ON
OFF
ON
OFF
LED BO 73221 GI
10223 U2>(>) Overvolt. is switched OFF (U2>(>)
OFF)
VoltageProtection OUT ON
OFF
* LED BO 73 23 1 GI
10224 U2>(>) Overvolt. is BLOCKED (U2>(>)
BLK)
VoltageProtection OUT ON
OFF
ON
OFF
LED BO 73241 GI
10225 Uph-e<(<) Undervolt. is switched OFF
(Uph-e<(<) OFF)
VoltageProtection OUT ON
OFF
* LED BO 73 25 1 GI
10226 Uph-e<(<) Undervolt. is BLOCKED (Uph-
e<(<) BLK)
VoltageProtection OUT ON
OFF
ON
OFF
LED BO 73261 GI
10227 Uph-ph<(<) Undervolt. is switched OFF
(Uph-ph<(<) OFF)
VoltageProtection OUT ON
OFF
* LED BO 73 27 1 GI
10228 Uphph<(<) Undervolt. is BLOCKED (Uph-
ph<(<) BLK)
VoltageProtection OUT ON
OFF
ON
OFF
LED BO 73281 GI
10229 U1<(<) Undervolt. is switched OFF
(U1<(<) OFF)
VoltageProtection OUT ON
OFF
* LED BO 73 29 1 GI
10230 U1<(<) Undervolt. is BLOCKED (U1<(<)
BLK)
VoltageProtection OUT ON
OFF
ON
OFF
LED BO 73301 GI
10231 Over-/Under-Voltage protection is ACTIVE
(U</> ACTIVE)
VoltageProtection OUT ON
OFF
* LED BO 73 31 1 GI
10240 Uph-e> Pickup (Uph-e> Pickup) Voltage Protection OUT * ON
OFF
LED BO 73402 GI
10241 Uph-e>> Pickup (Uph-e>> Pickup) Voltage Protection OUT * ON
OFF
LED BO 73412 GI
10242 Uph-e>(>) Pickup L1 (Uph-e>(>) PU L1) Voltage Protection OUT * ON
OFF
LED BO 73422 GI
10243 Uph-e>(>) Pickup L2 (Uph-e>(>) PU L2) Voltage Protection OUT * ON
OFF
LED BO 73432 GI
10244 Uph-e>(>) Pickup L3 (Uph-e>(>) PU L3) Voltage Protection OUT * ON
OFF
LED BO 73442 GI
10245 Uph-e> TimeOut (Uph-e> TimeOut) Voltage Protection OUT * * LED BO
10246 Uph-e>> TimeOut (Uph-e>> TimeOut) Voltage Protection OUT * * LED BO
10247 Uph-e>(>) TRIP command (Uph-e>(>)
TRIP)
VoltageProtection OUT * ON LED BO 73 47 2 GI
10255 Uph-ph> Pickup (Uphph> Pickup) Voltage Protection OUT * ON
OFF
LED BO 73552 GI
10256 Uph-ph>> Pickup (Uphph>> Pickup) Voltage Protection OUT * ON
OFF
LED BO 73562 GI
10257 Uph-ph>(>) Pickup L1-L2 (Uphph>(>)PU
L12)
VoltageProtection OUT * ON
OFF
LED BO 73572 GI
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
