Appendix
B-56
7SA6 Manual
C53000-G1176-C156-2
10314 Uph-e<(<) Pickup L3 (Uph-e<(<) PU L3) Voltage Protection OUT * ON
OFF
LED BO 73 114 2 GI
10315 Uph-e< TimeOut (Uph-e< TimeOut) Voltage Protection OUT * * LED BO
10316 Uph-e<< TimeOut (Uph-e<< TimeOut) Voltage Protection OUT * * LED BO
10317 Uph-e<(<) TRIP command (Uph-e<(<)
TRIP)
VoltageProtection OUT * ON LED BO 73 117 2 GI
10325 Uph-ph< Pickup (Uph-ph< Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 125 2 GI
10326 Uph-ph<< Pickup (Uph-ph<< Pickup) Voltage Protection OUT * ON
OFF
LED BO 73 126 2 GI
10327 Uphph<(<) Pickup L1-L2 (Uphph<(<)PU
L12)
VoltageProtection OUT * ON
OFF
LED BO 73 127 2 GI
10328 Uphph<(<) Pickup L2-L3 (Uphph<(<)PU
L23)
VoltageProtection OUT * ON
OFF
LED BO 73 128 2 GI
10329 Uphph<(<) Pickup L3-L1 (Uphph<(<)PU
L31)
VoltageProtection OUT * ON
OFF
LED BO 73 129 2 GI
10330 Uphph< TimeOut (Uphph< TimeOut) Voltage Protection OUT * * LED BO
10331 Uphph<< TimeOut (Uphph<< TimeOut) Voltage Protection OUT * * LED BO
10332 Uphph<(<) TRIP command (Uphph<(<)
TRIP)
VoltageProtection OUT * ON LED BO 73 132 2 GI
>Back Light on (>Light on) Device SP ON
OFF
*BI
>Cabinet door open (>Door open) Process Data SP on
off
* LED BI BO CB 101 1 1 GI
>CB waiting for Spring charged (>CB wait) Process Data SP on
off
* LED BI BO CB 101 2 1 GI
>Error Control Voltage (>ErrCntrlU) Process Data SP on
off
* LED BI BO CB 240 182 1 GI
>Error Meter (>Err Meter) Process Data SP on
off
* LED BI BO CB 240 184 1 GI
>Error Motor Voltage (>Err Mot U) Process Data SP on
off
* LED BI BO CB 240 181 1 GI
>SF6-Loss (>SF6-Loss) Process Data SP on
off
* LED BI BO CB 240 183 1 GI
>Transformer Danger (>Tx Danger) Process Data SP on
off
* LED BI BO CB 240 186 1 GI
>Transformer Temperature (>Tx Temp.) Process Data SP on
off
* LED BI BO CB 240 185 1 GI
Breaker (Breaker) Control Device CF_D12 on
off
*BO2401601GI
Breaker (Breaker) Control Device DP on
off
*BICB2401601GI
Breaker OPENED (Brk OPENED) Device IntSP * * LED BO
CB1-TEST trip/close Phases L123 (CB1tst
123)
Testing - * *
CB1-TEST trip/close - Only L1 (CB1tst L1) Testing - * *
CB1-TEST trip/close - Only L2 (CB1tst L2) Testing - * *
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information-No
Data Unit (ASDU)
General Interrogation
