Appendix
B-60
7SA6 Manual
C53000-G1176-C156-2
641 P (active power) (P =) Measurement 128 148 comp 9 7 CFC CD DD
134 124 priv 9 7
642 Q (reactive power) (Q =) Measurement 128 148 comp 9 8 CFC CD DD
134 124 priv 9 8
643 Power Factor (PF =) Measurement 134 124 priv 9 13 CFC CD DD
644 Frequency (Freq=) Measurement 128 148 comp 9 9 CFC CD DD
134 124 priv 9 9
645 S (apparent power) (S =) Measurement CFC CD DD
646 Frequency (busbar) (F-bus =) Measurement 130 1 priv 9 4 CFC CD DD
647 Frequency (difference line-bus) (F-diff=) Measurement 130 1 priv 9 5 CFC CD DD
648 Angle (difference line-bus) (ϕ-diff=) Measurement 130 1 priv 9 6 CFC CD DD
649 Frequency (line) (F-line=) Measurement 130 1 priv 9 7 CFC CD DD
701 Active 3I0sen (sensitive Ie) (3I0senA) Measurement 134 124 priv 9 15 CFC CD DD
702 Reactive 3I0sen (sensitive Ie) (3I0senR) Measurement 134 124 priv 9 16 CFC CD DD
801 Temperat. rise for warning and trip (Θ /Θtrip =) Measurement CFC CD DD
802 Temperature rise for phase L1 (Θ /ΘtripL1=) Measurement CFC CD DD
803 Temperature rise for phase L2 (Θ /ΘtripL2=) Measurement CFC CD DD
804 Temperature rise for phase L3 (Θ /ΘtripL3=) Measurement CFC CD DD
833 I1 (positive sequence) Demand (I1dmd =) Demand Mea-
surement Setup
CFC CD DD
834 Active Power Demand (Pdmd =) Demand Mea-
surement Setup
CFC CD DD
835 Reactive Power Demand (Qdmd =) Demand Mea-
surement Setup
CFC CD DD
836 Apparent Power Demand (Sdmd =) Demand Mea-
surement Setup
CFC CD DD
837 I L1 Demand Minimum (IL1d Min) Min/Max Mea-
surement Setup
CFC CD DD
838 I L1 Demand Maximum (IL1d Max) Min/Max Mea-
surement Setup
CFC CD DD
839 I L2 Demand Minimum (IL2d Min) Min/Max Mea-
surement Setup
CFC CD DD
840 I L2 Demand Maximum (IL2d Max) Min/Max Mea-
surement Setup
CFC CD DD
841 I L3 Demand Minimum (IL3d Min) Min/Max Mea-
surement Setup
CFC CD DD
842 I L3 Demand Maximum (IL3d Max) Min/Max Mea-
surement Setup
CFC CD DD
843 I1 (positive sequence) Demand Minimum (I1dmdMin) Min/Max Mea-
surement Setup
CFC CD DD
F.No. Description Function IEC 60870-5-103 Configurable in
Matrix
Function type
Information-No
Compatibility
Data Unit (ASDU)
Position
CFC
Control Display
Default Display
