Appendix
B-61
7SA6 Manual
C53000-G1176-C156-2
844 I1 (positive sequence) Demand Maximum
(I1dmdMax)
Min/Max Mea-
surement Setup
CFC CD DD
845 Active Power Demand Minimum (PdMin=) Min/Max Mea-
surement Setup
CFC CD DD
846 Active Power Demand Maximum (PdMax=) Min/Max Mea-
surement Setup
CFC CD DD
847 Reactive Power Demand Minimum (QdMin=) Min/Max Mea-
surement Setup
CFC CD DD
848 Reactive Power Demand Maximum (QdMax=) Min/Max Mea-
surement Setup
CFC CD DD
849 Apparent Power Demand Minimum (SdMin=) Min/Max Mea-
surement Setup
CFC CD DD
850 Apparent Power Demand Maximum (SdMax=) Min/Max Mea-
surement Setup
CFC CD DD
851 I L1 Minimum (IL1Min=) Min/Max Mea-
surement Setup
CFC CD DD
852 I L1 Maximum (IL1Max=) Min/Max Mea-
surement Setup
CFC CD DD
853 I L2 Mimimum (IL2Min=) Min/Max Mea-
surement Setup
CFC CD DD
854 I L2 Maximum (IL2Max=) Min/Max Mea-
surement Setup
CFC CD DD
855 I L3 Minimum (IL3Min=) Min/Max Mea-
surement Setup
CFC CD DD
856 I L3 Maximum (IL3Max=) Min/Max Mea-
surement Setup
CFC CD DD
857 Positive Sequence Minimum (I1 Min=) Min/Max Mea-
surement Setup
CFC CD DD
858 Positive Sequence Maximum (I1 Max=) Min/Max Mea-
surement Setup
CFC CD DD
859 U L1E Minimum (UL1EMin=) Min/Max Mea-
surement Setup
CFC CD DD
860 U L1E Maximum (UL1EMax=) Min/Max Mea-
surement Setup
CFC CD DD
861 U L2E Minimum (UL2EMin=) Min/Max Mea-
surement Setup
CFC CD DD
862 U L2E Maximum (UL2EMax=) Min/Max Mea-
surement Setup
CFC CD DD
863 U L3E Minimum (UL3EMin=) Min/Max Mea-
surement Setup
CFC CD DD
864 U L3E Maximum (UL3EMax=) Min/Max Mea-
surement Setup
CFC CD DD
865 U L12 Minimum (UL12Min=) Min/Max Mea-
surement Setup
CFC CD DD
867 U L12 Maximum (UL12Max=) Min/Max Mea-
surement Setup
CFC CD DD
F.No. Description Function IEC 60870-5-103 Configurable in
Matrix
Function type
Information-No
Compatibility
Data Unit (ASDU)
Position
CFC
Control Display
Default Display
To Next Page
