Appendix
B-62
7SA6 Manual
C53000-G1176-C156-2
868 U L23 Minimum (UL23Min=) Min/Max Mea-
surement Setup
CFC CD DD
869 U L23 Maximum (UL23Max=) Min/Max Mea-
surement Setup
CFC CD DD
870 U L31 Minimum (UL31Min=) Min/Max Mea-
surement Setup
CFC CD DD
871 U L31 Maximum (UL31Min=) Min/Max Mea-
surement Setup
CFC CD DD
874 U1 (positive sequence) Voltage Minimum (U1 Min =) Min/Max Mea-
surement Setup
CFC CD DD
875 U1 (positive sequence) Voltage Maximum (U1 Max =) Min/Max Mea-
surement Setup
CFC CD DD
880 Apparent Power Minimum (SMin=) Min/Max Mea-
surement Setup
CFC CD DD
881 Apparent Power Maximum (SMax=) Min/Max Mea-
surement Setup
CFC CD DD
882 Frequency Minimum (fMin=) Min/Max Mea-
surement Setup
CFC CD DD
883 Frequency Maximum (fMax=) Min/Max Mea-
surement Setup
CFC CD DD
963 I L1 demand (IL1dmd=) Demand Mea-
surement Setup
CFC CD DD
964 I L2 demand (IL2dmd=) Demand Mea-
surement Setup
CFC CD DD
965 I L3 demand (IL3dmd=) Demand Mea-
surement Setup
CFC CD DD
966 R L1E (R L1E=) Measurement CFC CD DD
967 R L2E (R L2E=) Measurement CFC CD DD
970 R L3E (R L3E=) Measurement CFC CD DD
971 R L12 (R L12=) Measurement CFC CD DD
972 R L23 (R L23=) Measurement CFC CD DD
973 R L31 (R L31=) Measurement CFC CD DD
974 X L1E (X L1E=) Measurement CFC CD DD
975 X L2E (X L2E=) Measurement CFC CD DD
976 X L3E (X L3E=) Measurement CFC CD DD
977 X L12 (X L12=) Measurement CFC CD DD
978 X L23 (X L23=) Measurement CFC CD DD
979 X L31 (X L31=) Measurement CFC CD DD
1040 Active Power Minimum Forward (Pmin Forw=) Min/Max Mea-
surement Setup
CFC CD DD
1041 Active Power Maximum Forward (Pmax Forw=) Min/Max Mea-
surement Setup
CFC CD DD
F.No. Description Function IEC 60870-5-103 Configurable in
Matrix
Function type
Information-No
Compatibility
Data Unit (ASDU)
Position
CFC
Control Display
Default Display
To Next Page
