Appendix
B-63
7SA6 Manual
C53000-G1176-C156-2
1042 Active Power Minimum Reverse (Pmin Rev =) Min/Max Mea-
surement Setup
CFC CD DD
1043 Active Power Maximum Reverse (Pmax Rev =) Min/Max Mea-
surement Setup
CFC CD DD
1044 Reactive Power Minimum Forward (Qmin Forw=) Min/Max Mea-
surement Setup
CFC CD DD
1045 Reactive Power Maximum Forward (Qmax Forw=) Min/Max Mea-
surement Setup
CFC CD DD
1046 Reactive Power Minimum Reverse (Qmin Rev =) Min/Max Mea-
surement Setup
CFC CD DD
1047 Reactive Power Maximum Reverse (Qmax Rev =) Min/Max Mea-
surement Setup
CFC CD DD
1048 Power Factor Minimum Forward (PFminForw=) Min/Max Mea-
surement Setup
CFC CD DD
1049 Power Factor Maximum Forward (PFmaxForw=) Min/Max Mea-
surement Setup
CFC CD DD
1050 Power Factor Minimum Reverse (PFmin Rev=) Min/Max Mea-
surement Setup
CFC CD DD
1051 Power Factor Maximum Reverse (PFmax Rev=) Min/Max Mea-
surement Setup
CFC CD DD
1052 Active Power Demand Forward (Pdmd Forw=) Demand Mea-
surement Setup
CFC CD DD
1053 Active Power Demand Reverse (Pdmd Rev =) Demand Mea-
surement Setup
CFC CD DD
1054 Reactive Power Demand Forward (Qdmd Forw=) Demand Mea-
surement Setup
CFC CD DD
1055 Reactive Power Demand Reverse (Qdmd Rev =) Demand Mea-
surement Setup
CFC CD DD
7751 Prot Int 1: Delay time (PI1 DT=) Statistics CFC DD
7753 Prot Int 1: Availability per minute (PI1A/m) Statistics CFC DD
7754 Prot Int 1: Availability per hour (PI1A/h) Statistics CFC DD
7761 Relay ID of 1. relay (Relay ID) Measurements
from relay 1
CFC DD
7781 Relay ID of 2. relay (Relay ID) Measurements
from relay 2
CFC DD
7801 Relay ID of 3. relay (Relay ID) Measurements
from relay 3
CFC DD
10102 Min. Zero Sequence Voltage 3U0 (3U0min =) Min/Max Mea-
surement Setup
CFC CD DD
10103 Max. Zero Sequence Voltage 3U0 (3U0max =) Min/Max Mea-
surement Setup
CFC CD DD
14000 IL1 (primary) (IL1 =) Measurements
from relay 1
CFC DD
14001 Angle IL1 (ϕIL1 =) Measurements
from relay 1
CFC DD
F.No. Description Function IEC 60870-5-103 Configurable in
Matrix
Function type
Information-No
Compatibility
Data Unit (ASDU)
Position
CFC
Control Display
Default Display
