Siemens siprotec 7SA6 User Manual

Appendix
B-64
7SA6 Manual
C53000-G1176-C156-2
14002 IL2 (primary) (IL2 =) Measurements
from relay 1
CFC DD
14003 Angle IL2 (ϕIL2 =) Measurements
from relay 1
CFC DD
14004 IL3 (primary) (IL3 =) Measurements
from relay 1
CFC DD
14005 Angle IL3 (ϕIL3 =) Measurements
from relay 1
CFC DD
14010 UL1E (primary) (UL1E =) Measurements
from relay 1
CFC DD
14011 Angle UL1E (ϕUL1E =) Measurements
from relay 1
CFC DD
14012 UL2E (primary) (UL2E =) Measurements
from relay 1
CFC DD
14013 Angle UL2E (ϕUL2E =) Measurements
from relay 1
CFC DD
14014 UL3E (primary) (UL3E =) Measurements
from relay 1
CFC DD
14015 Angle UL3E (ϕUL3E =) Measurements
from relay 1
CFC DD
14020 IL1 (primary) (IL1 =) Measurements
from relay 2
CFC DD
14021 Angle IL1 (ϕIL1 =) Measurements
from relay 2
CFC DD
14022 IL2 (primary) (IL2 =) Measurements
from relay 2
CFC DD
14023 Angle IL2 (ϕIL2 =) Measurements
from relay 2
CFC DD
14024 IL3 (primary) (IL3 =) Measurements
from relay 2
CFC DD
14025 Angle IL3 (ϕIL3 =) Measurements
from relay 2
CFC DD
14030 UL1E (primary) (UL1E =) Measurements
from relay 2
CFC DD
14031 Angle UL1E (ϕUL1E =) Measurements
from relay 2
CFC DD
14032 UL2E (primary) (UL2E =) Measurements
from relay 2
CFC DD
14033 Angle UL2E (ϕUL2E =) Measurements
from relay 2
CFC DD
14034 UL3E (primary) (UL3E =) Measurements
from relay 2
CFC DD
14035 Angle UL3E (ϕUL3E =) Measurements
from relay 2
CFC DD
14040 IL1 (primary) (IL1 =) Measurements
from relay 3
CFC DD
F.No. Description Function IEC 60870-5-103 Configurable in
Matrix
Function type Information-No Compatibility Data Unit (ASDU) Position CFC Control Display Default Display
