Appendix
B-65
7SA6 Manual
C53000-G1176-C156-2
14041 Angle IL1 (ϕIL1 =) Measurements
from relay 3
CFC DD
14042 IL2 (primary) (IL2 =) Measurements
from relay 3
CFC DD
14043 Angle IL2 (ϕIL2 =) Measurements
from relay 3
CFC DD
14044 IL3 (primary) (IL3 =) Measurements
from relay 3
CFC DD
14045 Angle IL3 (ϕIL3 =) Measurements
from relay 3
CFC DD
14050 UL1E (primary) (UL1E =) Measurements
from relay 3
CFC DD
14051 Angle UL1E (ϕUL1E =) Measurements
from relay 3
CFC DD
14052 UL2E (primary) (UL2E =) Measurements
from relay 3
CFC DD
14053 Angle UL2E (ϕUL2E =) Measurements
from relay 3
CFC DD
14054 UL3E (primary) (UL3E =) Measurements
from relay 3
CFC DD
14055 Angle UL3E (ϕUL3E =) Measurements
from relay 3
CFC DD
Lower setting limit for Power Factor (PF<) Set Points (Mea-
sured Values)
CFC
Upper setting limit for I1dmd (I1dmd>) Set Points (Mea-
sured Values)
CFC
Upper setting limit for IL1dmd (IL1dmd>) Set Points (Mea-
sured Values)
CFC
Upper setting limit for IL2dmd (IL2dmd>) Set Points (Mea-
sured Values)
CFC
Upper setting limit for IL3dmd (IL3dmd>) Set Points (Mea-
sured Values)
CFC
Upper setting limit for Pdmd (|Pdmd|>) Set Points (Mea-
sured Values)
CFC
Upper setting limit for Qdmd (|Qdmd|>) Set Points (Mea-
sured Values)
CFC
Upper setting limit for Sdmd (Sdmd>) Set Points (Mea-
sured Values)
CFC
F.No. Description Function IEC 60870-5-103 Configurable in
Matrix
Function type Information-No Compatibility Data Unit (ASDU) Position CFC Control Display Default Display
