Appendix
A.8 Settings
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
408
4303 T START MAX 48/66 Motorprot 1 .. 320 sec 10 sec Maximum Permissible Starting
Time
4304 T Equal 48/66 Motorprot 0.0 .. 320.0 min 1.0 min Temperature Equalizaton Time
4305 I MOTOR NOMINAL 48/66 Motorprot 1A 0.20 .. 1.20 A 1.00 A Rated Motor Current
5A 1.00 .. 6.00 A 5.00 A
4306 MAX.WARM STARTS 48/66 Motorprot 1 .. 4 2 Maximum Number of Warm
Starts
4307 #COLD-#WARM 48/66 Motorprot 1 .. 2 1 Number of Cold Starts - Warm
Starts
4308 Kτ at STOP 48/66 Motorprot 0.2 .. 100.0 5.0 Extension of Time Constant at
Stop
4309 Kτ at RUNNING 48/66 Motorprot 0.2 .. 100.0 2.0 Extension of Time Constant at
Running
4310 T MIN. INHIBIT 48/66 Motorprot 0.2 .. 120.0 min 6.0 min Minimum Restart Inhibit Time
4311 ROTOR OVERLOAD 48/66 Motorprot ON
OFF
Alarm Only
ON Rotor Overload Protection
4401 Load Jam Prot. 48/66 Motorprot OFF
ON
Alarm Only
OFF Load Jam Protection
4402 Load Jam I> 48/66 Motorprot 1A 0.50 .. 12.00 A 2.00 A Load Jam Tripping Threshold
5A 2.50 .. 60.00 A 10.00 A
4403 TRIP DELAY 48/66 Motorprot 0.00 .. 600.00 sec 1.00 sec Load Jam Trip Delay
4404 I Alarm 48/66 Motorprot 1A 0.50 .. 12.00 A 1.80 A Load Jam Alarm Threshold
5A 2.50 .. 60.00 A 9.00 A
4405 ALARM DELAY 48/66 Motorprot 0.00 .. 600.00 sec 1.00 sec Load Jam Alarm Delay
4406 T Start Blk. 48/66 Motorprot 0.00 .. 600.00 sec 10.00 sec Load Jam Blocking after motor
start
7001 FCT 50BF 50BF BkrFailure OFF
ON
OFF 50BF Breaker Failure Protection
7004 Chk BRK CONTACT 50BF BkrFailure OFF
ON
OFF Check Breaker contacts
7005 TRIP-Timer 50BF BkrFailure 0.06 .. 60.00 sec; ∞ 0.25 sec TRIP-Timer
7006 50BF PICKUP 50BF BkrFailure 1A 0.05 .. 20.00 A 0.10 A 50BF Pickup current threshold
5A 0.25 .. 100.00 A 0.50 A
7007 50BF PICKUP IE> 50BF BkrFailure 1A 0.05 .. 20.00 A 0.10 A 50BF Pickup earth current
threshold
5A 0.25 .. 100.00 A 0.50 A
7101 FCT 79 79M Auto Recl. OFF
ON
OFF 79 Auto-Reclose Function
7103 BLOCK MC Dur. 79M Auto Recl. 0.50 .. 320.00 sec; 0 1.00 sec AR blocking duration after
manual close
7105 TIME RESTRAINT 79M Auto Recl. 0.50 .. 320.00 sec 3.00 sec 79 Auto Reclosing reset time
7108 SAFETY 79 ready 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Safety Time until 79 is ready
7113 CHECK CB? 79M Auto Recl. No check
Chk each cycle
No check Check circuit breaker before AR?
7114 T-Start MONITOR 79M Auto Recl. 0.01 .. 320.00 sec; ∞ 0.50 sec AR start-signal monitoring time
7115 CB TIME OUT 79M Auto Recl. 0.10 .. 320.00 sec 3.00 sec Circuit Breaker (CB) Supervision
Time
7116 Max. DEAD EXT. 79M Auto Recl. 0.50 .. 1800.00 sec; ∞ 100.00 sec Maximum dead time extension
7117 T-ACTION 79M Auto Recl. 0.01 .. 320.00 sec; ∞∞sec Action time
7118 T DEAD DELAY 79M Auto Recl. 0.0 .. 1800.0 sec; ∞ 1.0 sec Maximum Time Delay of Dead-
Time Start
7127 DEADTIME 1: PH 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 1: Phase Fault
7128 DEADTIME 1: G 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 1: Ground Fault
7129 DEADTIME 2: PH 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 2: Phase Fault
7130 DEADTIME 2: G 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 2: Ground Fault
7131 DEADTIME 3: PH 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 3: Phase Fault
7132 DEADTIME 3: G 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 3: Ground Fault
7133 DEADTIME 4: PH 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 4: Phase Fault
7134 DEADTIME 4: G 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 4: Ground Fault
Addr. Parameter Function C Setting Options Default Setting Comments
