Appendix
A.8 Settings
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
409
7135 # OF RECL. GND 79M Auto Recl. 0 .. 9 1 Number of Reclosing Cycles
Ground
7136 # OF RECL. PH 79M Auto Recl. 0 .. 9 1 Number of Reclosing Cycles
Phase
7137 Cmd.via control 79M Auto Recl. (Setting options depend
on configuration)
None Close command via control
device
7139 External SYNC 79M Auto Recl. YES
NO
NO External 25 synchronisation
7140 ZONE SEQ.COORD. 79M Auto Recl. OFF
ON
OFF ZSC - Zone sequence coordina-
tion
7150 50-1 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50-1
7151 50N-1 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50N-1
7152 50-2 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50-2
7153 50N-2 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50N-2
7154 51 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 51
7155 51N 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 51N
7162 sens Ground Flt 79M Auto Recl. No influence
Starts 79
Stops 79
No influence (Sensitive) Ground Fault
7163 46 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 46
7164 BINARY INPUT 79M Auto Recl. No influence
Starts 79
Stops 79
No influence Binary Input
7165 3Pol.PICKUP BLK 79M Auto Recl. YES
NO
NO 3 Pole Pickup blocks 79
7166 50-3 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50-3
7167 50N-3 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50N-3
7200 bef.1.Cy:50-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50-1
7201 bef.1.Cy:50N-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50N-1
7202 bef.1.Cy:50-2 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50-2
7203 bef.1.Cy:50N-2 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50N-2
7204 bef.1.Cy:51 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 51
7205 bef.1.Cy:51N 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 51N
7212 bef.2.Cy:50-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50-1
7213 bef.2.Cy:50N-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50N-1
Addr. Parameter Function C Setting Options Default Setting Comments
