Siemens SIPROTEC 7SJ61

Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
420
273 Set Point Phase A dmd> (SP. I A
dmd>)
Set Points(MV) OUT On
Off
* * LED BO 135 230 1 Yes
274 Set Point Phase B dmd> (SP. I B
dmd>)
Set Points(MV) OUT On
Off
* * LED BO 135 234 1 Yes
275 Set Point Phase C dmd> (SP. I C
dmd>)
Set Points(MV) OUT On
Off
* * LED BO 135 235 1 Yes
276 Set Point positive sequence
I1dmd> (SP. I1dmd>)
Set Points(MV) OUT On
Off
* * LED BO 135 236 1 Yes
284 Set Point 37-1 Undercurrent
alarm (SP. 37-1 alarm)
Set Points(MV) OUT On
Off
* * LED BO 135 244 1 Yes
301 Power System fault
(Pow.Sys.Flt.)
Device, General OUT On
Off
On
Off
135 231 2 Yes
302 Fault Event (Fault Event) Device, General OUT * on 135 232 2 Yes
303 sensitive Ground fault (sens Gnd
flt)
Device, General OUT On
Off
* ON 135 233 1 Yes
320 Warn: Limit of Memory Data ex-
ceeded (Warn Mem. Data)
Device, General OUT On
Off
**LEDBO
321 Warn: Limit of Memory Parameter
exceeded (Warn Mem. Para.)
Device, General OUT On
Off
**LEDBO
322 Warn: Limit of Memory Operation
exceeded (Warn Mem. Oper.)
Device, General OUT On
Off
**LEDBO
323 Warn: Limit of Memory New ex-
ceeded (Warn Mem. New)
Device, General OUT On
Off
**LEDBO
356 >Manual close signal (>Manual
Close)
P.System Data 2 SP * * * LED BI BO 150 6 1 Yes
395 >I MIN/MAX Buffer Reset (>I
MinMax Reset)
Min/Max meter SP on * * LED BI BO
396 >I1 MIN/MAX Buffer Reset (>I1
MiMaReset)
Min/Max meter SP on * * LED BI BO
403 >Idmd MIN/MAX Buffer Reset
(>Idmd MiMaReset)
Min/Max meter SP on * * LED BI BO
409 >BLOCK Op Counter (>BLOCK
Op Count)
Statistics SP On
Off
* LED BI BO
412 >Theta MIN/MAX Buffer Reset (>
Θ MiMa Reset)
Min/Max meter SP on * * LED BI BO
501 Relay PICKUP (Relay PICKUP) P.System Data 2 OUT ON m LED BO 150 151 2 Yes
502 Relay Drop Out (Relay Drop Out) Device, General SP * *
510 General CLOSE of relay (Relay
CLOSE)
Device, General SP * *
511 Relay GENERAL TRIP command
(Relay TRIP)
P.System Data 2 OUT ON m LED BO 150 161 2 Yes
533 Primary fault current Ia (Ia =) P.System Data 2 VI On
Off
150 177 4 No
534 Primary fault current Ib (Ib =) P.System Data 2 VI On
Off
150 178 4 No
535 Primary fault current Ic (Ic =) P.System Data 2 VI On
Off
150 179 4 No
545 Time from Pickup to drop out (PU
Time)
Device, General VI
546 Time from Pickup to TRIP (TRIP
Time)
Device, General VI
561
Manual close signal detected
(Man.Clos.Detect)
P.System Data 2 OUT On
Off
**LEDBO
916 Increment of active energy
(Wp∆=)
Energy -
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
