Siemens SIPROTEC 7SJ61

Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
421
917 Increment of reactive energy
(Wq∆=)
Energy -
1020 Counter of operating hours
(Op.Hours=)
Statistics VI
1021 Accumulation of interrupted
current Ph A (Σ Ia =)
Statistics VI
1022 Accumulation of interrupted
current Ph B (Σ Ib =)
Statistics VI
1023 Accumulation of interrupted
current Ph C (Σ Ic =)
Statistics VI
1202 >BLOCK 50Ns-2 (>BLOCK
50Ns-2)
Sens. Gnd Fault SP On
Off
* * LED BI BO 151 102 1 Yes
1203 >BLOCK 50Ns-1 (>BLOCK
50Ns-1)
Sens. Gnd Fault SP On
Off
* * LED BI BO 151 103 1 Yes
1204 >BLOCK 51Ns (>BLOCK 51Ns) Sens. Gnd Fault SP On
Off
* * LED BI BO 151 104 1 Yes
1207 >BLOCK 50Ns/67Ns (>BLK
50Ns/67Ns)
Sens. Gnd Fault SP On
Off
* * LED BI BO 151 107 1 Yes
1211 50Ns/67Ns is OFF (50Ns/67Ns
OFF)
Sens. Gnd Fault OUT On
Off
* * LED BO 151 111 1 Yes
1212 50Ns/67Ns is ACTIVE
(50Ns/67Ns ACT)
Sens. Gnd Fault OUT On
Off
* * LED BO 151 112 1 Yes
1221 50Ns-2 Pickup (50Ns-2 Pickup) Sens. Gnd Fault OUT * On
Off
On
Off
* LED BO 151 121 2 Yes
1223 50Ns-2 TRIP (50Ns-2 TRIP) Sens. Gnd Fault OUT * on On
Off
m LED BO 151 123 2 Yes
1224 50Ns-1 Pickup (50Ns-1 Pickup) Sens. Gnd Fault OUT * On
Off
On
Off
* LED BO 151 124 2 Yes
1226 50Ns-1 TRIP (50Ns-1 TRIP) Sens. Gnd Fault OUT * on On
Off
m LED BO 151 126 2 Yes
1227 51Ns picked up (51Ns Pickup) Sens. Gnd Fault OUT * On
Off
* LED BO 151 127 2 Yes
1229 51Ns TRIP (51Ns TRIP) Sens. Gnd Fault OUT * on m LED BO 151 129 2 Yes
1230 Sensitive ground fault detection
BLOCKED (Sens. Gnd block)
Sens. Gnd Fault OUT On
Off
On
Off
* LED BO 151 130 1 Yes
1403 >BLOCK 50BF (>BLOCK 50BF) 50BF BkrFailure SP On
Off
* * LED BI BO 166 103 1 Yes
1431 >50BF initiated externally
(>50BF ext SRC)
50BF BkrFailure SP On
Off
* * LED BI BO 166 104 1 Yes
1451 50BF is switched OFF (50BF
OFF)
50BF BkrFailure OUT On
Off
* * LED BO 166 151 1 Yes
1452 50BF is BLOCKED (50BF
BLOCK)
50BF BkrFailure OUT On
Off
On
Off
* LED BO 166 152 1 Yes
1453 50BF is ACTIVE (50BF ACTIVE) 50BF BkrFailure OUT On
Off
* * LED BO 166 153 1 Yes
1456 50BF (internal) PICKUP (50BF int
Pickup)
50BF BkrFailu
re OUT * On
Off
* LED BO 166 156 2 Yes
1457 50BF (external) PICKUP (50BF
ext Pickup)
50BF BkrFailure OUT * On
Off
* LED BO 166 157 2 Yes
1471 50BF TRIP (50BF TRIP) 50BF BkrFailure OUT * on m LED BO 160 85 2 No
1480 50BF (internal) TRIP (50BF int
TRIP)
50BF BkrFailure OUT * on * LED BO 166 180 2 Yes
1481 50BF (external) TRIP (50BF ext
TRIP)
50BF BkrFailure OUT * on * LED BO 166 181 2 Yes
1503 >BLOCK 49 Overload Protection
(>BLOCK 49 O/L)
49 Th.Overload SP * * * LED BI BO 167 3 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
