Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
423
1763 50/51 Phase B picked up (50/51
Ph B PU)
50/51 Overcur. OUT * On
Off
m LED BO 160 65 2 Yes
1764 50/51 Phase C picked up (50/51
Ph C PU)
50/51 Overcur. OUT * On
Off
m LED BO 160 66 2 Yes
1765 50N/51N picked up
(50N/51NPickedup)
50/51 Overcur. OUT * On
Off
m LED BO 160 67 2 Yes
1767 50-3 picked up (50-3 picked up) 50/51 Overcur. OUT * On
Off
* LED BO
1768 50N-3 picked up (50N-3 picked
up)
50/51 Overcur. OUT * On
Off
* LED BO
1769 50-3 TRIP (50-3 TRIP) 50/51 Overcur. OUT * on * LED BO
1770 50N-3 TRIP (50N-3 TRIP) 50/51 Overcur. OUT * on * LED BO
1787 50-3 TimeOut (50-3 TimeOut) 50/51 Overcur. OUT * * * LED BO
1788 50N-3 TimeOut (50N-3 TimeOut) 50/51 Overcur. OUT * * * LED BO
1791 50(N)/51(N) TRIP
(50(N)/51(N)TRIP)
50/51 Overcur. OUT * on m LED BO 160 68 2 No
1800 50-2 picked up (50-2 picked up) 50/51 Overcur. OUT * On
Off
* LED BO 60 75 2 Yes
1804 50-2 Time Out (50-2 TimeOut) 50/51 Overcur. OUT * * * LED BO 60 49 2 Yes
1805 50-2 TRIP (50-2 TRIP) 50/51 Overcur. OUT * on m LED BO 160 91 2 No
1810 50-1 picked up (50-1 picked up) 50/51 Overcur. OUT * On
Off
* LED BO 60 76 2 Yes
1814 50-1 Time Out (50-1 TimeOut) 50/51 Overcur. OUT * * * LED BO 60 53 2 Yes
1815 50-1 TRIP (50-1 TRIP) 50/51 Overcur. OUT * on m LED BO 160 90 2 No
1820 51 picked up (51 picked up) 50/51 Overcur. OUT * On
Off
* LED BO 60 77 2 Yes
1824 51 Time Out (51 Time Out) 50/51 Overcur. OUT * * * LED BO 60 57 2 Yes
1825 51 TRIP (51 TRIP) 50/51 Overcur. OUT * on m LED BO 60 58 2 Yes
1831 50N-2 picked up (50N-2 picked
up)
50/51 Overcur. OUT * On
Off
* LED BO 60 59 2 Yes
1832 50N-2 Time Out (50N-2 TimeOut) 50/51 Overcur. OUT * * * LED BO 60 60 2 Yes
1833 50N-2 TRIP (50N-2 TRIP) 50/51 Overcur. OUT * on m LED BO 160 93 2 No
1834 50N-1 picked up (50N-1 picked
up)
50/51 Overcur. OUT * On
Off
* LED BO 60 62 2 Yes
1835 50N-1 Time Out (50N-1 TimeOut) 50/51 Overcur. OUT * * * LED BO 60 63 2 Yes
1836 50N-1 TRIP (50N-1 TRIP) 50/51 Overcur. OUT * on m LED BO 160 92 2 No
1837 51N picked up (51N picked up) 50/51 Overcur. OUT * On
Off
* LED BO 60 64 2 Yes
1838 51N Time Out (51N TimeOut) 50/51 Overcur. OUT * * * LED BO 60 65 2 Yes
1839 51N TRIP (51N TRIP) 50/51 Overcur. OUT * on m LED BO 60 66 2 Yes
1840 Phase A inrush detection (PhA
InrushDet)
50/51 Overcur. OUT * On
Off
* LED BO 60 101 2 Yes
1841 Phase B inrush detection (PhB
InrushDet)
50/51 Overcur. OUT * On
Off
* LED BO 60 102 2 Yes
1842 Phase C inrush detection (PhC
InrushDet)
50/51 Overcur. OUT * On
Off
* LED BO 60 103 2 Yes
1843 Cross blk: PhX blocked PhY
(INRUSH X-BLK)
50/51 Overcur. OUT * On
Off
* LED BO 60 104 2 Yes
1851 50-1 BLOCKED (50-1
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 105 1 Yes
1852 50-2 BLOCKED (50-2
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 106 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
