Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
424
1853 50N-1 BLOCKED (50N-1
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 107 1 Yes
1854 50N-2 BLOCKED (50N-2
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 108 1 Yes
1855 51 BLOCKED (51 BLOCKED) 50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 109 1 Yes
1856 51N BLOCKED (51N BLOCKED) 50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 110 1 Yes
1866 51 Disk emulation Pickup (51
Disk Pickup)
50/51 Overcur. OUT * * * LED BO
1867 51N Disk emulation picked up
(51N Disk Pickup)
50/51 Overcur. OUT * * * LED BO
1994 Cold-Load-Pickup switched OFF
(CLP OFF)
ColdLoadPickup OUT On
Off
* * LED BO 60 244 1 Yes
1995 Cold-Load-Pickup is BLOCKED
(CLP BLOCKED)
ColdLoadPickup OUT On
Off
On
Off
* LED BO 60 245 1 Yes
1996 Cold-Load-Pickup is RUNNING
(CLP running)
ColdLoadPickup OUT On
Off
* * LED BO 60 246 1 Yes
1997 Dynamic settings are ACTIVE
(Dyn set. ACTIVE)
ColdLoadPickup OUT On
Off
* * LED BO 60 247 1 Yes
2701 >79 ON (>79 ON) 79M Auto Recl. SP On
Off
**LEDBIBO4011Yes
2702 >79 OFF (>79 OFF) 79M Auto Recl. SP On
Off
**LEDBIBO4021Yes
2703 >BLOCK 79 (>BLOCK 79) 79M Auto Recl. SP On
Off
**LEDBIBO4031Yes
2711 >79 External start of internal A/R
(>79 Start)
79M Auto Recl. SP * On
Off
* LED BI BO
2715 >Start 79 Ground program (>Start
79 Gnd)
79M Auto Recl. SP * on * LED BI BO 40 15 2 Yes
2716 >Start 79 Phase program (>Start
79 Ph)
79M Auto Recl. SP * on * LED BI BO 40 16 2 Yes
2720 >Enable 50/67-(N)-2 (override 79
blk) (>Enable ANSI#-2)
P.System Data 2 SP On
Off
**LEDBIBO40201Yes
2722 >Switch zone sequence coordi-
nation ON (>ZSC ON)
79M Auto Recl. SP On
Off
**LEDBIBO
2723 >Switch zone sequence coordi-
nation OFF (>ZSC OFF)
79M Auto Recl. SP On
Off
**LEDBIBO
2730 >Circuit breaker READY for re-
closing (>CB Ready)
79M Auto Recl. SP On
Off
**LEDBIBO40301Yes
2731 >79: Sync. release from ext.
sync.-check (>Sync.release)
79M Auto Recl. SP * on * LED BI BO
2753 79: Max. Dead Time Start Delay
expired (79 DT delay ex.)
79M Auto Recl. OUT on * * LED BO
2754 >79: Dead Time Start Delay (>79
DT St.Delay)
79M Auto Recl. SP On
Off
**
LEDBIBO
2781 79 Auto recloser is switched OFF
(79 OFF)
79M Auto Recl. OUT on * * LED BO 40 81 1 Yes
2782 79 Auto recloser is switched ON
(79 ON)
79M Auto Recl. IntSP On
Off
* * LED BO 160 16 1 Yes
2784 79 Auto recloser is NOT ready
(79 is NOT ready)
79M Auto Recl. OUT On
Off
* * LED BO 160 130 1 Yes
2785 79 - Auto-reclose is dynamically
BLOCKED (79 DynBlock)
79M Auto Recl. OUT On
Off
on * LED BO 40 85 1 Yes
2788 79: CB ready monitoring window
expired (79 T-CBreadyExp)
79M Auto Recl. OUT on * * LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
