Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
425
2801 79 - in progress (79 in progress) 79M Auto Recl. OUT * on * LED BO 40 101 2 Yes
2808 79: CB open with no trip (79 BLK:
CB open)
79M Auto Recl. OUT On
Off
**LEDBO
2809 79: Start-signal monitoring time
expired (79 T-Start Exp)
79M Auto Recl. OUT on * * LED BO
2810 79: Maximum dead time expired
(79 TdeadMax Exp)
79M Auto Recl. OUT on * * LED BO
2823 79: no starter configured (79 no
starter)
79M Auto Recl. OUT On
Off
**LEDBO
2824 79: no cycle configured (79 no
cycle)
79M Auto Recl. OUT On
Off
**LEDBO
2827 79: blocking due to trip (79 BLK
by trip)
79M Auto Recl. OUT on * * LED BO
2828 79: blocking due to 3-phase
pickup (79 BLK:3ph p.u.)
79M Auto Recl. OUT on * * LED BO
2829 79: action time expired before trip
(79 Tact expired)
79M Auto Recl. OUT on * * LED BO
2830 79: max. no. of cycles exceeded
(79 Max. No. Cyc)
79M Auto Recl. OUT on * * LED BO
2844 79 1st cycle running (79 1stCyc.
run.)
79M Auto Recl. OUT * on * LED BO
2845 79 2nd cycle running (79 2ndCyc.
run.)
79M Auto Recl. OUT * on * LED BO
2846 79 3rd cycle running (79 3rdCyc.
run.)
79M Auto Recl. OUT * on * LED BO
2847 79 4th or higher cycle running (79
4thCyc. run.)
79M Auto Recl. OUT * on * LED BO
2851 79 - Close command (79 Close) 79M Auto Recl. OUT * on m LED BO 160 128 2 No
2862 79 - cycle successful (79 Suc-
cessful)
79M Auto Recl. OUT on on * LED BO 40 162 1 Yes
2863 79 - Lockout (79 Lockout) 79M Auto Recl. OUT on on * LED BO 40 163 2 Yes
2865 79: Synchro-check request (79
Sync.Request)
79M Auto Recl. OUT * on * LED BO
2878 79-A/R single phase reclosing se-
quence (79 L-N Sequence)
79M Auto Recl. OUT * on * LED BO 40 180 2 Yes
2879 79-A/R multi-phase reclosing se-
quence (79 L-L Sequence)
79M Auto Recl. OUT * on * LED BO 40 181 2 Yes
2883 Zone Sequencing is active (ZSC
active)
79M Auto Recl. OUT On
Off
on * LED BO
2884 Zone sequence coordination
switched ON (ZSC ON)
79M Auto Recl. OUT on * * LED BO
2885 Zone sequence coordination
switched OFF (ZSC OFF)
79M Auto Recl. OUT on * * LED BO
2889 79 1st cycle zone extension
release (79 1.CycZoneRel)
79M Auto Recl. OUT * * * LED BO
2890 79 2nd cycle zone extension
release (79 2.CycZoneRel)
79M Auto Recl. OUT * * * LED BO
2891 79 3rd cycle zone extension
release (79 3.CycZoneRel)
79M Auto Recl. OUT * * * LED BO
2892 79 4th cycle zone extension
release (79 4.CycZoneRel)
79M Auto Recl. OUT * * * LED BO
2896 No. of 1st AR-cycle CLOSE com-
mands,3pole (79 #Close1./3p=)
Statistics VI
2898 No. of higher AR-cycle CLOSE
commands,3p (79 #Close2./3p=)
Statistics VI
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
