Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
427
5962 50 1Ph is BLOCKED (50 1Ph
BLOCKED)
50 1Ph OUT On
Off
On
Off
* LED BO
5963 50 1Ph is ACTIVE (50 1Ph
ACTIVE)
50 1Ph OUT On
Off
**LEDBO
5966 50 1Ph-1 is BLOCKED (50 1Ph-1
BLK)
50 1Ph OUT On
Off
On
Off
* LED BO
5967 50 1Ph-2 is BLOCKED (50 1Ph-2
BLK)
50 1Ph OUT On
Off
On
Off
* LED BO
5971 50 1Ph picked up (50 1Ph
Pickup)
50 1Ph OUT * On
Off
* LED BO
5972 50 1Ph TRIP (50 1Ph TRIP) 50 1Ph OUT * on * LED BO
5974 50 1Ph-1 picked up (50 1Ph-1
PU)
50 1Ph OUT * On
Off
* LED BO
5975 50 1Ph-1 TRIP (50 1Ph-1 TRIP) 50 1Ph OUT * on * LED BO
5977 50 1Ph-2 picked up (50 1Ph-2
PU)
50 1Ph OUT * On
Off
* LED BO
5979 50 1Ph-2 TRIP (50 1Ph-2 TRIP) 50 1Ph OUT * on * LED BO
5980 50 1Ph: I at pick up (50 1Ph I:) 50 1Ph VI * On
Off
6801 >BLOCK Startup Supervision
(>BLK START-SUP)
48/66 Motorprot SP * * * LED BI BO
6805 >Rotor locked (>Rotor locked) 48/66 Motorprot SP * * * LED BI BO
6811 Startup supervision OFF (START-
SUP OFF)
48/66 Motorprot OUT On
Off
* * LED BO 169 51 1 Yes
6812 Startup supervision is BLOCKED
(START-SUP BLK)
48/66 Motorprot OUT On
Off
On
Off
* LED BO 169 52 1 Yes
6813 Startup supervision is ACTIVE
(START-SUP ACT)
48/66 Motorprot OUT On
Off
* * LED BO 169 53 1 Yes
6821 Startup supervision TRIP
(START-SUP TRIP)
48/66 Motorprot OUT * on m LED BO 169 54 2 Yes
6822 Rotor locked (Rotor locked) 48/66 Motorprot OUT * on * LED BO 169 55 2 Yes
6823 Startup supervision Pickup
(START-SUP pu)
48/66 Motorprot OUT On
Off
* * LED BO 169 56 1 Yes
6851 >BLOCK 74TC (>BLOCK 74TC) 74TC TripCirc. SP * * * LED BI BO
6852 >74TC Trip circuit superv.: trip
relay (>74TC trip rel.)
74TC TripCirc. SP On
Off
* * LED BI BO 170 51 1 Yes
6853 >74TC Trip circuit superv.: bkr
relay (>74TC brk rel.)
74TC TripCirc. SP On
Off
* * LED BI BO 170 52 1 Yes
6861 74TC Trip circuit supervision OFF
(74TC OFF)
74TC TripCirc. OUT On
Off
* * LED BO 170 53 1 Yes
6862 74TC Trip circuit supervision is
BLOCKED (74TC BLOCKED)
74TC TripCirc. OUT On
Off
On
Off
* LED BO 153 16 1 Yes
6863 74TC Trip circuit supervision is
ACTIVE (74TC ACTIVE)
74TC TripCirc. OUT On
Of
f
* * LED BO 153 17 1 Yes
6864 74TC blocked. Bin. input is not
set (74TC ProgFail)
74TC TripCirc. OUT On
Off
* * LED BO 170 54 1 Yes
6865 74TC Failure Trip Circuit (74TC
Trip cir.)
74TC TripCirc. OUT On
Off
* * LED BO 170 55 1 Yes
6903 >block interm. E/F prot. (>IEF
block)
Intermit. EF SP * * * LED BI BO 152 1 1 Yes
6921 Interm. E/F prot. is switched off
(IEF OFF)
Intermit. EF OUT On
Off
* * LED BO 152 10 1 Yes
6922 Interm. E/F prot. is blocked (IEF
blocked)
Intermit. EF OUT On
Off
On
Off
* LED BO 152 11 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
