Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
428
6923 Interm. E/F prot. is active (IEF en-
abled)
Intermit. EF OUT On
Off
* * LED BO 152 12 1 Yes
6924 Interm. E/F detection stage Iie>
(IIE Fault det)
Intermit. EF OUT * * * LED BO
6925 Interm. E/F stab detection (IIE
stab.Flt)
Intermit. EF OUT * * * LED BO
6926 Interm.E/F det.stage Iie> f.Flt.
ev.Prot (IIE Flt.det FE)
Intermit. EF OUT * on * 152 13 2 No
6927 Interm. E/F detected (Inter-
mitt.EF)
Intermit. EF OUT * On
Off
* LED BO 152 14 2 Yes
6928 Counter of det. times elapsed
(IEF Tsum exp.)
Intermit. EF OUT * on * LED BO 152 15 2 No
6929 Interm. E/F: reset time running
(IEF Tres run.)
Intermit. EF OUT * On
Off
* LED BO 152 16 2 Yes
6930 Interm. E/F: trip (IEF Trip) Intermit. EF OUT * on * LED BO 152 17 2 No
6931 Max RMS current value of fault =
(Iie/In=)
Intermit. EF VI On
Off
* 152 18 4 No
6932 No. of detections by stage Iie>=
(Nos.IIE=)
Intermit. EF VI On
Off
* 152 19 4 No
7551 50-1 InRush picked up (50-1 In-
RushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 80 2 Yes
7552 50N-1 InRush picked up (50N-1
InRushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 81 2 Yes
7553 51 InRush picked up (51 InRush-
PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 82 2 Yes
7554 51N InRush picked up (51N In-
RushPU)
50/51 Overcur. OUT * On
Off
* LED BO 60 83 2 Yes
7556 InRush OFF (InRush OFF) 50/51 Overcur. OUT On
Off
**LEDBO60921Yes
7557 InRush BLOCKED (InRush BLK) 50/51 Overcur. OUT On
Off
On
Off
* LED BO 60 93 1 Yes
7558 InRush Ground detected (InRush
Gnd Det)
50/51 Overcur. OUT * On
Off
* LED BO 60 94 2 Yes
7563 >BLOCK InRush (>BLOCK
InRush)
50/51 Overcur. SP * * * LED BI BO
7564 Ground InRush picked up (Gnd
InRush PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 88 2 Yes
7565 Phase A InRush picked up (Ia
InRush PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 89 2 Yes
7566 Phase B InRush picked up (Ib
InRush PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 90 2 Yes
7567 Phase C InRush picked up (Ic
InRush PU)
50/51 Overcur. OUT * On
Off
* LED BO 60 91 2 Yes
10020 >BLOCK Load Jam Protection
(>BLOCK Jam Prot)
48/66 Motorprot SP On
Off
LED BI BO
10021 Load Jam Protection is
BLOCKED (JAM PROT.BLOCK.)
48/66 Motorprot OUT On
Of
f
LED BO
10022 Load Jam Protection is OFF
(JAM PROT.OFF)
48/66 Motorprot OUT On
Off
LED BO
10023 Load Jam Protection is ACTIVE
(JAM PROT.ACTIVE)
48/66 Motorprot OUT On
Off
LED BO
10024 Load Jam Protection alarm (Load
Jam alarm)
48/66 Motorprot OUT On
Off
* LED BO
10025 Load Jam Protection picked up
(Load Jam pickup)
48/66 Motorprot OUT On
Off
* LED BO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
