Siemens SIPROTEC 7SJ61 - Page 429

Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
429
10026 Load Jam Protection TRIP (Load
Jam TRIP)
48/66 Motorprot OUT On
Off
* LED BO
10027 Startup Duration 1
(StartDuration1)
Mot.Statistics VI
10028 Startup Current 1
(StartupCurrent1)
Mot.Statistics VI
10029 Startup Voltage 1
(StartupVoltage1)
Mot.Statistics VI
10030 Total Number of Motor Starts
(Nr.of Mot.Start)
Mot.Statistics VI
10031 Total Motor Running Time (Motor
Run.Time)
Mot.Statistics VI
10032 Total Motor Stopped Time (Motor
Stop.Time)
Mot.Statistics VI
10033 Motor Percent Running Time
(Perc.Run.Time)
Mot.Statistics VI
10034 50-3 BLOCKED (50-3
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO
10035 50N-3 BLOCKED (50N-3
BLOCKED)
50/51 Overcur. OUT On
Off
On
Off
* LED BO
10037 Startup Duration 2
(StartDuration2)
Mot.Statistics VI
10038 Startup Current 2
(StartupCurrent2)
Mot.Statistics VI
10039 Startup Voltage 2
(StartupVoltage2)
Mot.Statistics VI
10040 Startup Duration 3
(StartDuration3)
Mot.Statistics VI
10041 Startup Current 3
(StartupCurrent3)
Mot.Statistics VI
10042 Startup Voltage 3
(StartupVoltage3)
Mot.Statistics VI
10043 Startup Duration 4
(StartDuration4)
Mot.Statistics VI
10044 Startup Current 4
(StartupCurrent4)
Mot.Statistics VI
10045 Startup Voltage 4
(StartupVoltage4)
Mot.Statistics VI
10046 Startup Duration 5
(StartDuration5)
Mot.Statistics VI
10047 Startup Current 5
(StartupCurrent5)
Mot.Statistics VI
10048 Startup Voltage 5
(StartupVoltage5)
Mot.Statistics VI
14101 Fail: RTD (broken wire/shorted)
(Fail: RTD)
RTD-Box OUT On
Off
**LEDBO
14111 Fail: RTD 1 (broken wire/shorted)
(Fail: RTD 1)
RTD-Box OUT On
Off
**LEDBO
14112 RTD 1 Temperature stage 1
picked up (RTD 1 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14113 RTD 1 Temperature stage 2
picked up (RTD 1 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
14121 Fail: RTD 2 (broken wire/shorted)
(Fail: RTD 2)
RTD-Box OUT On
Off
**LEDBO
14122 RTD 2 Temperature stage 1
picked up (R
TD 2 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
