Functions
130
7SS52 V4 Manual
C53000-G1176-C182-1
5.3.8 List of Information from the Central Unit
$00, .., $03 are variables which will be automatically replaced by
$00 Number of the bay unit
$01 Bay name
$02 Name of the switching element (e.g. isolator or circuit breaker)
$03 Name of the bus zone
FNo. Alarm Comments
10436 TRIP BF M Trip command BF (group alarm)
10437 BF ImpBI errorM Timing error BF impulse input (g. a.)
10478 >EF charact. >Earth fault characteristic active
176.1091 BFBIErr $00 L1 Timing error BF input $00 L1
176.1092 BFBIErr $00 L2 Timing error BF input $00 L2
176.1093 BFBIErr $00 L3 Timing error BF input $00 L3
176.1094 BFBIErr $00 3P Timing error BF input $00 3pole
176.1101 BFRlErr $00 1P Timing error BF release $00 1pole
176.1102 BFRlErr $00 3P Timing error BF release $00 3pole
176.1104 BFBIImpErr $00 Timing error BF impulse input $00
176.1171 15V-superv $00 15V supply supervision $00
176.1172 5V-superv $00 5V supply supervision $00
176.1173 0V-superv $00 0V supply supervision $00
176.1175 MeasInSup $00 Measured value supervision I-SUM $00
