tion to be generated. So, when the respective user-defined annunciation is displayed
as ON in the bay unit, at the same time it seems as if a binary input to which this binary
input annunciation is configured was activated by a binary signal. Chapter A.10, page
372 gives an overview of the configurable input functions with the corresponding func-
tion numbers (FNo.).
5.17.2 Setting Notes
T-Annunc.1
T-Annunc.2
T-Annunc.3
T-Annunc.4
The parameters T-Annunc.1 (2801/BU), T-Annunc.2 (2802/BU),
T-Annunc.3 (2803/BU) and T-Annunc.4 (2804/BU) are used to set the delay
times for the user-defined annunciations 1, 2, 3 and 4.
5.17.3 Settings of the Bay Unit
Addr. Parameters Setting Options Default Settings Comments
2801 T-Annunc.1 0.00..10.00 s 0.00 s Delay time for 1st user defined
annunciation
2802 T-Annunc.2 0.00..10.00 s 0.00 s Delay time for 2nd user defined
annunciation
2803 T-Annunc.3 0.00..10.00 s 0.00 s Delay time for 3rd user defined
annunciation
2804 T-Annunc.4 0.00..10.00 s 0.00 s Delay time for 4th user defined
annunciation
2811 ANNUN1byCU NO
YES
NO Processing of annunciation 1 by
central unit
2812 ANNUN2byCU NO
YES
NO Processing of annunciation 2 by
central unit
2813 ANNUN3byCU NO
YES
NO Processing of annunciation 3by
central unit
2814 ANNUN4byCU NO
YES
NO Processing of annunciation 4 by
central unit
2821 ANN1Fct.Nr 0..9999 0 Binary input annunciation
(Fct.nr) by annunc.1
2822 ANN2Fct.Nr 0..9999 0 Binary input annunciation
(Fct.nr) by annunc.2
2823 ANN3Fct.Nr 0..9999 0 Binary input annunciation
(Fct.nr) by annunc.3
2824 ANN4Fct.Nr 0..9999 0 Binary input annunciation
(Fct.nr) by annunc.4
