A.10 List of Information - Bay Unit
FNo. Short Text Logical Function Log Buffers Configurable
in Matrix
IEC 60870-5-103
Event Log On/Off
Measured Value
Trip (Fault) Log On/Off
Binary Input I
Binary Output O
(LED, alarm relay)
Trip Relay T
Data Unit
Compatible Annunciation
General Interrogation
Annunc. for Fault Rec. Buffer
(Tagged)
Type (p: Corresponds to
parameter “Function type“)
Information Number
3 >Time Synchro >Time synchronization IO
4 >Start FltRec >Start fault recording on IO
5 >LED reset >Reset LED indicators IO
7 >ParamSelec.1 >Parameter group selection 1
(with >ParamSelec2)
IO
8 >ParamSelec.2 >Parameter group selection 2
(with >ParamSelec1)
IO
11 >Annunc. 1 >User defined annunciation 1 on/off IOT 1 CA GI TA p 27
12 >Annunc. 2 >User defined annunciation 2 on/off IOT 1 CA GI TA p 28
13 >Annunc. 3 >User defined annunciation 3 on/off IOT 1 CA GI TA p 29
14 >Annunc. 4 >User defined annunciation 4 on/off IOT 1 CA GI TA p 30
51 Dev.operative Device operative / healthy on/off 1 GI 135 81
52 Prot. operat. Any protection operative on/off O 1 CA GI p 18
55 Reset Device on 1 CA p 4
56 Initial start Initial start of processor system on 1 CA p 5
59 Real time response to LSA on 1
60 LED reset LED Reset on O 1 CA p 19
61 LogMeasBlock Logging and measuring functions blocked on/off 1 CA GI p 20
62 Test mode Test mode on/off 1 CA GI p 21
95 Param.running Parameters are being set on/off 1 CA GI p 22
100 Wrong SW-vers Wrong software-version on
101 Wrong dev. ID Wrong device identification on
110 Annunc. lost Annunciations lost (buffer overflow) on 1 135 130
111 Annu. PC lost Annunciations for PC lost on
112 Annunciations for LSA lost on 1 135 131
113 Fault tag lost 1 TA 135 136
115 Flt.Buff.Over Fault annunciation buffer overflow on
116 E.F. Buff.Over E/F buffer overflow
120 Oper.Ann.Inva Operational annunciations invalid on/off
121 Flt.Ann.Inval Fault annunciations invalid on/off
122 E/F.Prot Inva Earth fault annunciations invalid on/off
123 Stat.Buff.Inv Statistic annunciation buffer invalid on/off
124 LED Buff.Inva LED annunciation buffer invalid on/off
129 VDEW-StateInv VDEW state invalid on/off
135 Chs Error Error in check sum on/off
140 General internal failure of device on/off 1 CA GI p 47
143 Failure 15V Failure of internal 15 VDC power supply on/off 1 GI 135 163
144 Failure 5V Failure of internal 5 VDC power supply on/off 1 GI 135 164
