List of information - Central Unit
371
7SS52 V4 Manual
C53000-G1176-C182-1
177.1354 Trip command BF for $03 phase
L3 (Trip BF $03 L3)
Protection Zone OUT * k * LED REL
177.1360 >Trip command for $03 (>Trip
$03)
Protection Zone SP k g * * LED BE REL FS
177.1361 Timing error external Trip
command $03 (TripBIErr $03)
Protection Zone OUT * k * LED REL
177.1362 No release of Trip command $03
(noTripRel $03)
Protection Zone OUT * k * LED REL
177.1363 Trip command by BI for $03 (Trip
BI $03)
Protection Zone OUT * * * LED REL
- Clock Synchronization (Synch-
Clock)
Device IntSP
_Ev
**LEDREL
- Disturbance CFC (Distur.CFC) Device OUT k g * * LED REL
- Fault Recording Start (FltRecSta) Osc. Fault Rec. IntSP k g * m LED REL 135 208 1 no
- Hardware Test Mode (HWTest-
Mod)
Device IntSP k g * * LED REL
- Reset LED (Reset LED) Device IntSP k * * LED REL 194 19 1 no
- Reset meter (Meter res) Protec. general IntSP
_Ev
KBE
- Stop data transmission (DataS-
top)
Device IntSP k g * LED REL 194 20 1 yes
- Test mode (Test mode) Device IntSP k g * LED REL 194 21 1 yes
- Unlock data transmission via BI
(UnlockDT)
Device IntSP * * * LED REL
FNo. Description Function Type
ofIn-
for-
matio
n
Log-Buffer Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information No.
Data Unit
General Interrogation
