PC Port of the Bay Unit
177
7SS52 V4 Manual
C53000-G1176-C182-1
5.12 PC Port of the Bay Unit
5.12.1 Functional Description
The device is equipped with an operating interface integrated in the front panel, the
so-called PC port. Communication through this port is subject to certain agreements
concerning the transmission formation and the transmission rate.
The data entered must match the connected device.
5.12.2 Setting Notes
FUNCT. TYP With the parameter FUNCT. TYP (7208/BU) you set the compatible functions type for
the transmission of your device with IEC61870-5-103.
The function type 160 (definite time mode) must be selected for the bay units.
PC INTERF. The parameter PC INTERF. (7211/BU) is used to select the format for transmitting
data from the front port (PC port) to the device connected to it.
With setting DIGSI V3, the data are transmitted in a format which is used by
DIGSI V3.
With setting ASCII, the data are transmitted in ASCII format.
PC BAUDRATE The parameter PC BAUDRATE (7215/BU) is used to select the rate at which data will
be transmitted from the front port (PC port) to the device connected to it.
With setting 1200, 2400, 4800, 9600 or 19200 BAUD, the data will be transmitted at
the selected rate.
PC PARITY The parameter PC PARITY (7216/BU) is used to select the parity for transmission
of data from the front port (PC port) to the device connected to it.
With setting DIGSI V3, the data are transmitted with a parity used by DIGSI V3.
With setting No parity, 2 stopbits, data are transmitted without parity and with
2 stop bits.
With setting No parity, 1 stopbit, data are transmitted without parity and with
one stop bit.
