Appendix
370
7SS52 V4 Manual
C53000-G1176-C182-1
176.1172 5V supply supervision $00 (5V-
superv $00)
BU OUT k g * * LED REL
176.1173 0V supply supervision $00 (0V-
superv $00)
BU OUT k g * * LED REL
176.1174 Battery supervision $00 (BattSu-
perv $00)
BU OUT k g * * LED REL
176.1175 Measured value supervision I-
SUM $00 (MeasInSup $00)
BU OUT k g * * LED REL
176.1190 Failure in automatic testing $00
(Flt aut $00)
BU OUT_
Ev
k* LED REL
176.1195 Transformer reversed in polarity
$00 (TF RevPol $00)
BU OUT k g * * LED REL
176.1339 Block Trip command for BB by
$00 (BlkTrip BB $00)
BU OUT k g * * LED REL
176.1349 Block BF protection for BB by $00
(BlkBF BB $00)
BU OUT k g * * LED REL
176.1365 Timing error back-up BF input
$00 (BF BUBIErr $00)
BU OUT k g * * LED REL
177.1321 Id-sup $03 L1-2 (Id-supL1-2 $03) Protection Zone OUT k g * * LED REL
177.1322 Id-sup $03 L2-2 (Id-supL2-2 $03) Protection Zone OUT k g * * LED REL
177.1323 Id-sup $03 L3-2 (Id-supL3-2 $03) Protection Zone OUT k g * * LED REL
177.1326 Id-sup $03 L1-3 (Id-supL1-3 $03) Protection Zone OUT k g * * LED REL
177.1327 Id-sup $03 L2-3 (Id-supL2-3 $03) Protection Zone OUT k g * * LED REL
177.1328 Id-sup $03 L3-3 (Id-supL3-3 $03) Protection Zone OUT k g * * LED REL
177.1331 Id-sup $03 M (Id-sup $03 M) Protection Zone OUT * * * LED REL
177.1332 Transfer Trip $03 (TrfTrip $03) Protection Zone OUT * k * LED REL
177.1333 Blocked by fault $03 ($03 blocked
Flt)
Protection Zone OUT k g * * LED REL
177.1334 >Block $03 (>Blk $03) Protection Zone SP k g * * LED BE REL FS
177.1335 Blocked by BI $03 ($03 blocked
BI)
Protection Zone OUT k g * * LED REL
177.1336 >Block Trip command for $03
(>Blk Trip $03)
Protection Zone SP k g * * LED BE REL FS
177.1337 Block Trip command $03 ($03
BlkTrip)
Protection Zone IntSP k g * * LED REL
177.1338 Blocked Trip command $03 ($03
BlkdTrip)
Protection Zone OUT k g * * LED REL
177.1341 Trip command for $03 (group
alarm) (Trip $03 M)
Protection Zone OUT * * * LED REL
177.1342 Trip command for $03 L1 (Trip
$03 L1)
Protection Zone OUT * k * LED REL
177.1343 Trip command for $03 L2 (Trip
$03 L2)
Protection Zone OUT * k * LED REL
177.1344 Trip command for $03 L3 (Trip
$03 L3)
Protection Zone OUT * k * LED REL
177.1346 >Block BF protection for $03
(>Blk BF $03)
Protection Zone SP k g * * LED BE REL FS
177.1347 Block BF protection for $03 ($03
BlkBF)
Protection Zone IntSP k g * * LED REL
177.1348 Blocked BF protection for $03
($03 BlkdBF)
Protection Zone OUT k g * * LED REL
177.1352 Trip command BF for $03 phase
L1 (Trip BF $03 L1)
Protection Zone OUT * k * LED REL
177.1353 Trip command BF for $03 phase
L2 (Trip BF $03 L2)
Protection Zone OUT * k * LED REL
FNo. Description Function Type
ofIn-
for-
matio
n
Log-Buffer Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Chatter Blocking
Type
Information No.
Data Unit
General Interrogation
To Next Page
